Description
Bently Nevada 3300 XL Armored Vibration Sensor
5-meter industrial probe with country-specific certifications. Made in USA. 12-month warranty. Ships via FedEx/UPS/DHL.
Complete Product Details
| Manufacturer | Bently Nevada |
| Full Model Number | 330707-00-15-50-01-CN |
| Case Length | 1.5 inch (15 option) |
| Cable Length | 5.0 meters (50 option) |
| Connector Type | ClickLoc with protector (01 option) |
| Certification | Country Specific (CN option) |
Core Technical Specifications
- Sensing Range: 11mm proximity detection
- Electrical Resistance: 7.2Ω ±0.8 (center to outer)
- Thread Size: 1/2-20 UNF
- Armor Material: Heavy-duty stainless steel
- Cable Type: Standard triaxial (75Ω FEP insulated)
- Min Bend Radius: 25.4mm (1 inch)
- Weight: 0.17 kg per unit
Performance & Limits
- Temp Range: -51°C to +177°C
- Max Thread Depth: 0.750 inch
- Installation Torque: 15.2 N•m (133 in•lb)
- Max Torque: 45.2 N•m (400 in•lb)
- Seal Warning: Avoid below -34°C
Setup Requirements
- Must pair with 5-meter Proximitor sensors only
- Hand-tighten connectors (max 0.565 N•m)
- Keep cables straight near probe tip
- Use thread sealant for pressure applications
Compatibility Notes
- Works with Bently Nevada 3300 monitoring systems
- Country-specific approvals included
- Not compatible with 1m/9m sensor units
What You Receive
- Armored probe with 5m cable
- ClickLoc connector set
- Manufacturer documentation
- 12-month warranty card
Common Questions Answered
Q: Can I cut the cable to shorter length?
A: No – cutting voids warranty and affects calibration
Q: Is this explosion-proof?
A: Not inherently – check local certifications
Q: How soon can I install after cold shipping?
A: Warm to +5°C before installation
Q: Can I use in saltwater environments?
A: Yes – stainless steel resists corrosion
