Product Overview
The Bently Nevada 125840-01 High Voltage AC Power Input Module is a critical component of the 3500 series monitoring system. Designed to convert high-voltage AC (up to 600VAC) to low-voltage DC power, it ensures reliable operation of sensors and monitors in demanding industrial environments with 90% efficiency.
Technical Data
- Part Number: 125840-01
- Input Voltage:
- 175–264VAC RMS (47–63Hz)
- Peak Range: 247–373VAC
- Output Current: 2.3A RMS (max)
- Efficiency: Up to 90%
Key Features
- Backplane-mounted design for seamless integration
- Wide operating temperature: -30°C to +65°C
- Compact dimensions: 120.7mm × 25.4mm × 114.3mm
- Lightweight: 0.34kg (0.75lb)
| Parameter | Specification |
|---|---|
| Humidity Tolerance | 0–95% non-condensing |
| Storage Temperature | -40°C to +85°C |
| Mounting | 3500 system backplane |
Industrial Applications
- Power Generation: Turbine monitoring in coal/gas-fired plants
- Oil & Gas: Compressor stations and pipeline monitoring
- Heavy Industry: Rolling mill motor protection in steel plants
Compliance Support: For technical documentation, contact sales@ubestplc.com.
