Description
Bently Nevada 3300 NSv Reverse Mount Probe
Technical Specifications
- Brand: Bently Nevada
- Full Suffix: 330907-05-30-50-02-00
– Threads: M10X1 reverse mount
– Cable: 5.0m standard (16.4 ft)
– Connector: Mini coaxial ClickLoc (02)
– Approvals: Not required (00)
- Range: 0.25-1.75mm linear displacement
- Output: -1 to -13 Vdc
- Resistance: 5.3 ± 0.7 Ω at 5.0m
- Temp Range: -52°C to +177°C
- Response Time: <2 ms
- Hysteresis: <1% full scale
Installation Guide
- Optimal Gap: Set at 1.0mm (40 mils)
- Torque Spec: 7.5 N•m (66 in•lb)
- Wiring: Use 0.2-1.5mm² shielded triad cable
- Max Run: 305m to monitor
- Seal Warning: Avoid prolonged exposure below -34°C
Compatibility
- – 3300 XL NSv Proximitor systems
- – GE/Bently Nevada monitoring gear
- – API 670 compliant machinery
- – M10X1 threaded mounts
Package Contents
- – 3300 NSv Probe assembly
- – Optional COO documentation
- – 12-month defect warranty
- Global shipping via FedEx/UPS/DHL
Technical Comparison
| Model | Cable Length | Connector | Approvals | Details |
|---|---|---|---|---|
| 330907-05-30-50-02-00 | 5.0m | Standard | None | Current model |
| 330907-05-30-10-02-05 | 1.0m | Standard | Multiple | Shorter cable |
| 330907-05-30-05-02-00 | 0.5m | Standard | None | Ultra-short cable |
Frequently Asked Questions
- What’s the difference between FluidLoc and standard cable?
Standard cable (02) lacks FluidLoc’s oil-resistant jacketing
- How does temperature affect accuracy?
<0.5% signal drift across operating range
- Can I use this in explosive environments?
Not ATEX certified (option 00)
- What maintenance is required?
Annual gap verification and connector inspection
- Is calibration included?
Factory-calibrated; field calibration recommended yearly
