Description
Bently Nevada 3300 XL Proximity Probe
Product Identification
Full Part Number: 330708-00-10-10-01-00
- Brand: Bently Nevada
- Type: 3300 XL 11 mm Probe
- Made in USA
- Thread: 5/8-18 UNF (no armor)
Configuration Details
- 00 – Unthreaded length: 0 inch
- 10 – Case length: 1.0 inch
- 10 – Cable length: 1.0 meter
- 01 – ClickLoc connector with protector
- 00 – No agency approvals required
Key Specifications
| Electrical Resistance | 5.9 ± 0.5 Ω |
| Thread Engagement | Max 0.938 inch |
| Installation Torque | 15.2 N•m (133 in•lb) |
| Temperature Limits | -51°C to +177°C |
| Cable Type | 75 Ω triaxial FEP |
| Bend Radius | 25.4 mm minimum |
Installation Guide
- Hand-tighten plus quarter turn
- Avoid temperatures below -34°C to protect seals
- Use on shafts larger than 11 mm diameter
Package & Support
- New in factory packaging
- Shipping: FedEx / UPS / DHL
- Warranty: 12 months
- Weight: 0.17 kg
- Optional Certificate of Origin available
Frequently Asked Questions
Q: What is the cable length?
A: This model has 1.0 meter cable
Q: Can this probe handle high pressure?
A: Features Viton O-ring seal (contact for pressure testing)
Q: Is this waterproof?
A: Sealed for differential pressure between tip and case
Q: What connectors does it use?
A: Miniature coaxial ClickLoc with protector
