Description
Bently Nevada 3300 XL Proximity Probe – 11mm Industrial Sensor
Complete Product Identification
Full Part Number: 330708-00-24-10-12-05
- Base Model: 330708 (3300 XL 11mm Probe)
- Thread: 5/8-18 UNF without armor
- Unthreaded Length: 00 = 0 inch
- Case Length: 24 = 2.4 inch
- Cable Length: 10 = 1.0 meter
- Connector: 12 = Miniature ClickLoc with FluidLoc
- Approvals: 05 = Multiple certifications
Key Technical Parameters
- Electrical Resistance: 5.9Ω ±0.5 at 1m
- Thread Engagement: 0.938 inch max
- Torque Setting: 15.2 N•m recommended
- Bend Radius: 25.4mm minimum
- Temperature Limit: -51°C to +177°C
- Cable Type: 75Ω triaxial FEP insulation
- Seal Material: Viton O-ring pressure seal
- Weight: 0.17kg (lightweight design)
Installation Specifications
- Thread: 5/8-18 UNF industrial standard
- Max torque: 45.2 N•m (400 in•lb)
- Connector torque: Finger tight + 0.565 N•m max
- Storage warning: Avoid below -34°C to protect seals
Quality Assurance
- Made in USA with certified materials
- Optional Certificate of Origin (COO)
- 12-month warranty
- New in factory packaging
Global Shipping
Fast delivery worldwide via:
- FedEx International Priority
- UPS Worldwide Saver
- DHL Express
Frequently Asked Questions
Q: What thread size does this probe have?
A: Industrial 5/8-18 UNF thread pattern
Q: Can I get documentation of origin?
A: Yes, Certificate of Origin (COO) available
Q: What temperature damages the seals?
A: Storage below -34°C (-30°F) may harm pressure seals
Q: Is this version armored?
A: No armor – standard stainless steel housing
Q: What cable length options exist?
A: Available in 1m, 5m, and 9m versions
