3300 XL 11 mm Proximity Probe Metric – Bently Nevada 330704

Description

Product Description

Bently Nevada 3300 XL 11 mm Proximity Probe measures vibration and position. Model 330704-000-050-10-02-05 is metric. It works with turbines, compressors, and pumps. This sensor gives reliable data for machine protection. New unit comes in original factory packing. 12-month warranty included.

Why Choose This 11 mm Probe

• High accuracy for critical rotating machinery.
• Strong resistance to magnetic fields up to 300 Gauss.
• Wide temperature range from -52°C to +177°C.
• Durable AISI 304 stainless steel case.
• Easy installation with M14x1.5 thread.

Key Technical Data

• Brand: Bently Nevada
• Model: 330704-000-050-10-02-05
• Series: 3300 XL 11 mm Proximity Probes, Metric
• Measurement range: 0.5 mm to 4.6 mm gap
• Frequency response: DC to 10 kHz typical
• Sensitivity: 7.87 mV/μm (200 mV/mil) typical with 3300 XL driver
• Linearity: ±0.025 mm from 0.5 mm to 2.5 mm gap
• Resolution: 0.1 μm typical
• Temperature range (operating & storage): -52°C to +177°C
• Environmental tolerance: withstands -34°C without pressure seal failure
• Anti-interference: 60 Hz magnetic fields up to 300 Gauss, output as low as 0.001 V/Gauss at 0.5 mm gap

Detailed Specifications

• Probe DC resistance: 5.9 ± 0.5 ohms for 1.0 meter length
• Tip material: Polyphenylene sulfide (PPS)
• Case material: AISI 304 stainless steel
• Cable type: 75 Ω triaxial, FEP insulated, 1.0 meter total length
• Connector: Miniature coaxial ClickLoc, standard cable
• Thread size: M14x1.5
• Max thread engagement: 21 mm
• Recommended torque: 21.1 N•m (187 in•lb)
• Maximum torque: 63.3 N•m (560 in•lb)

Ordering Code Breakdown

• 330704 = 3300 XL 11 mm Probe, M14 x 1.5 thread, with armor
• 000 = Unthreaded length 00 mm
• 050 = Overall case length 50 mm
• 10 = Total length 1.0 metre (3.3 feet)
• 02 = Miniature coaxial ClickLoc connector, standard cable
• 05 = Multiple agency approvals

Temperature Classification (EPL Ga/Gc)

• T1: -55°C to +232°C
• T2: -55°C to +177°C
• T3: -55°C to +120°C
• T4: -55°C to +80°C
• T5: -55°C to +40°C

Installation Guide

• Use M14x1.5 mating thread.
• Apply 21.1 N•m recommended torque. Do not exceed 63.3 N•m.
• Keep thread engagement within 21 mm max.
• Avoid exposing probe below -34°C before use. This prevents pressure seal damage.
• Match with 3300 XL driver for best performance.

Maintenance & Setup Ease

• ClickLoc connector allows quick cable attachment.
• No special tools needed for routine inspection.
• Probe tip resists chemical and thermal stress.
• Armored cable option reduces wear in tight spaces.

Compatibility

• Works with all Bently Nevada 3300 XL driver modules.
• Fits standard 5 mm and 8 mm probe holders.
• Compatible with Bently Nevada 3500 and 1900 monitoring systems.

Certifications & Approvals

• Agency Approval Option 05: Multiple global approvals.
• EPL Ga, Gc, Dc ratings for hazardous areas.
• Temperature classifications T1 to T5 as listed above.

Packing List

• 1x 330704-000-050-10-02-05 probe assembly
• 1x factory calibration certificate
• 1x installation manual
• Original factory packing box

Warranty & Shipping

• 12-month factory warranty from Bently Nevada.
• Fast delivery via FedEx, UPS, DHL.
• Global tracking number provided.

Typical Applications & Diagnostic Ability

• Monitor shaft vibration in steam turbines.
• Detect thrust position in centrifugal compressors.
• Measure eccentricity in gas turbines.
• Diagnose bearing wear and imbalance online.
• Works with predictive maintenance systems.

FAQ – Frequently Asked Questions

• What is the standard cable length for this model?
• Total length is 1.0 metre (3.3 feet). Option 10 means 1 meter.
• Can I use this probe with a 3300 XL 5 mm driver?
• No. Use only 3300 XL 11 mm driver for correct linearity.
• What happens if I over-torque the probe?
• Over-torque above 63.3 N•m can damage threads or case.
• Why does the probe show higher output in magnetic fields at larger gaps?
• At 4.6 mm gap, interference is 0.027 V/Gauss. Keep gap below 2.5 mm for best noise immunity.
• Can I cut and splice the probe cable?
• No. Cutting changes 75 Ω impedance and ruins accuracy.
• How do I store spare probes?
• Store at room temperature, away from solvents. Keep protective cap on tip.
• Do you have stock for 5 meter or 9 meter versions?
• This listing is for 1 meter. Contact us for longer lengths.

Selection Guide – How to Order Right

• Step 1: Choose unthreaded length. 000 = 00 mm for most standard holders.
• Step 2: Select case length. 050 = 50 mm fits deep mountings.
• Step 3: Pick total probe length. 10 = 1 meter for short runs. Use 5 or 9 meters for long distance.
• Step 4: Connector 02 (ClickLoc) is best for quick changes. Avoid 03 for high vibration.
• Step 5: Approval 05 (multiple) is recommended for global use. Choose 00 for domestic only.
• Pro tip: For ambient temperature above 120°C, select T1 or T2 classification. Below -40°C, verify cable flexibility.
