Description
Bently Nevada 3300 XL Proximity Probe with FluidLoc Cable
Product Identification
- Manufacturer: Bently Nevada
- Part Number: 330708-00-10-10-12-00
- Type: 11 mm Proximity Probe
- Origin: Made in USA
- Condition: Factory new in sealed packaging
Suffix Configuration Breakdown
- 330708 – Base model (5/8-18 UNF thread)
- 00 – Unthreaded length: 0 inch
- 10 – Case length: 1.0 inch
- 10 – Cable length: 1.0 meter
- 12 – ClickLoc connector with FluidLoc cable
- 00 – No agency approvals
Technical Specifications
| Cable Type | FluidLoc FEP triaxial |
| Electrical Resistance | 5.9 ± 0.5 Ω |
| Thread Size | 5/8-18 UNF |
| Max Torque | 15.2 N•m |
| Bend Radius | 25.4 mm minimum |
| Temp Range | -51°C to +177°C |
Installation Notes
- Max thread engagement: 0.938 inch
- Finger tighten plus 1/4 turn
- Keep above -34°C to protect seals
- Minimum bend: 25.4 mm
Shipping & Support
- Weight: 0.17 kg
- Delivery: FedEx / UPS / DHL
- Warranty: 12 months
- Made in USA certification available
Frequently Asked Questions
Q: What makes FluidLoc cable special?
A: Enhanced protection in wet conditions
Q: Minimum operating temperature?
A: -34°C to prevent seal damage
Q: Thread compatibility?
A: 5/8-18 UNF standard
Q: Pressure rating?
A: Viton sealed (custom testing available)
