Description
Bently Nevada 3300 XL 11mm Proximity Probe – Industrial Precision Monitoring
Premium vibration monitoring probe for critical machinery protection. Made in USA with 12-month warranty. Ships via FedEx/UPS/DHL.
Key Specifications
- Brand: Bently Nevada
- Full Model: 330708-00-24-50-11-00
- Probe Type: 3300 XL 11mm
- Cable Length: 5.0 meters (16.4 ft)
- Resistance: 7.2Ω ±0.8 (center to outer conductor)
- Thread Size: 5/8-18 UNF
- Case Material: AISI 304 Stainless Steel
- Tip Material: PPS (Polyphenylene sulfide)
- Connector: Miniature coaxial ClickLoc with protector
- Cable Type: 75Ω triaxial FluidLoc (FEP insulated)
Technical Performance
- Temp Range: -51°C to +177°C (-60°F to +351°F)
- Max Thread Engagement: 0.938 in (23.8mm)
- Case Torque: Recommended 15.2 N•m (133 in•lb) / Max 45.2 N•m
- Bend Radius: 25.4mm (1.0 in) minimum
- Seal Material: Viton O-ring
Installation Notes
- For use only with 5-meter Proximitor sensors
- Maintain minimum bend radius during routing
- Apply recommended torque to avoid damage
- Avoid temperatures below -34°C (-30°F) to preserve seal integrity
Compatibility & Certifications
- Compatible with Bently Nevada 3300 XL monitoring systems
- Agency approvals: Not required (00 option)
Package Includes
- 3300 XL Probe with pre-attached cable
- Connector protector
- Product documentation
Warranty & Shipping
- 12-month manufacturer warranty
- Worldwide shipping via FedEx, UPS, DHL
- Shipping weight: 0.17 kg
Frequently Asked Questions
Q: Can this probe withstand wet environments?
A: Yes, FluidLoc cable provides moisture resistance
Q: Is pressure testing included?
A: Not standard – contact for custom pressure testing
Q: What’s the lead time?
A: Typically ships within 3-5 business days
