Bently Nevada 3300 XL Proximity Probe: Precision Machinery Monitoring
Core Product Details
Manufacturer: Bently Nevada | Part Number: 330708-00-24-50-12-00 | Made in USA
Industrial-grade 11mm proximity probe with 5/8-18 UNF threading and triaxial FluidLoc cable. Designed for use with 5-meter Proximitor Sensors only.
Full Suffix Breakdown
- 330708: 3300 XL 11mm Probe (5/8-18 UNF)
- 00: 0 inch unthreaded length
- 24: 2.4 inch case length
- 50: 5.0 meter cable length
- 12: ClickLoc connector + FluidLoc cable
- 00: No agency approval required
Critical Specifications
Electrical
- DC Resistance: 7.2Ω ±0.8Ω
- Cable Type: 75Ω triaxial FEP
- Impedance: 75Ω
Mechanical
- Thread: 5/8-18 UNF
- Max Thread Engagement: 0.938 inch
- Case Torque: 15.2 N•m (recommended)
- Bend Radius: 25.4mm minimum
Environmental
- Operating Temp: -51°C to +177°C
- Warning: Below -34°C risks seal failure
- Pressure Seal: Viton O-ring design
Installation Parameters
- Connector Torque: 0.565 N•m maximum
- Mounting: Requires 5-meter Proximitor Sensor
- Material: AISI 304 stainless steel case
- Tip: PPS (Polyphenylene sulfide)
Compatibility Notes
Designed exclusively for use with Bently Nevada 5-meter Proximitor Sensor systems. Not compatible with 9-meter sensor configurations.
Certification & Origin
- Agency Approval: Not required (option 00)
- Origin: Made in USA
- Optional: Certificate of Origin (COO)
Shipping Information
Weight: 0.17 kg | Carriers: FedEx, UPS, DHL | Warranty: 12 months
Technical FAQ
Q: Minimum installation temperature?
A: Do not install below -34°C to prevent seal damage
Q: Cable length alternatives?
A: Available in 1m, 5m, or 9m configurations
Q: Pressure testing available?
A: Custom testing through our design department
Q: Triaxial cable benefits?
A: Enhanced noise immunity in EMI environments
Installation Tip: Download the full specification sheet for torque diagrams and temperature guidelines
