Description
Bently Nevada 330904-08-15-05-01-05 – Premium Proximity Probe for Industrial Monitoring
New & original 3300 NSv Proximity Probe with factory warranty. Engineered for precision vibration measurement in demanding environments.
Technical Specifications
- Brand: Bently Nevada
- Model: 330904-08-15-05-01-05
- Thread Type: M8X1 with stainless steel armor
- Unthreaded Length: 80 mm (-08)
- Case Length: 150 mm (-15)
- Cable Length: 0.5 meter (-05)
- Connector: Miniature coaxial ClickLoc with protector (-01)
- Range: 1.5 mm (60 mils) linear range
- Accuracy: ±0.06 mm deviation from straight line
- Output Signal: -1 to -13 Vdc (7.87 V/mm scale factor)
- Temperature Range: -52°C to +177°C (-62°F to +351°F)
- Probe Resistance: 4.0 ± 0.5 ohms (0.5m cable)
Installation Guide
- Recommended Gap: 1.0 mm (40 mils) from target
- Torque Setting: Finger tight + max 0.56 N•m (5 in•lb)
- Min. Bend Radius: 25.4 mm (1.0 in)
- Thread Engagement: Max 12 mm for M8x1 thread
Compatibility
Direct replacement for 3300 RAM probes with improved performance. Works with existing Bently Nevada monitoring systems.
Certifications
Multiple agency approvals (-05 option) for global industrial use.
Package & Warranty
- Original factory packaging
- 12-month warranty
- Shipping via FedEx, UPS, or DHL worldwide
FAQ
- Q: Minimum target size?
A: 8.9mm diameter (13mm recommended) - Q: Compatible with 3300 RAM systems?
A: Yes, fully interchangeable - Q: Maximum cable length?
A: 305 meters between probe and monitor
