Allen-Bradley 1734-ADNX DeviceNet Adapter | Point I/O Network

Description

Allen-Bradley 1734-ADNX DeviceNet Adapter | Point I/O Network Interface

Connect your Point I/O system to DeviceNet networks with the versatile 1734-ADNX adapter. This communication interface enables seamless control and monitoring of I/O modules.

Installation Resources

• Complete installation and configuration guide available
• Includes network setup and wiring diagrams
• Download Point I/O Manual Here

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1734-ADNX
• Series: Point I/O
• Module Type: DeviceNet Adapter
• Input Voltage: 24V DC (SELV/PELV)
• Field Side Power: 400mA
• Inrush Current: 6A
• Power Consumption: 8.1W
• POINTBus Current: 1000mA @ 5V DC
• Power Dissipation: 2.8W @ 28.8V
• Status Indicators: 3 red/green, 2 green power
• Operating Temperature: 32°F to 140°F (0°C to 60°C)
• Mounting Position: Left side of 1734 system

Compatibility Information

• Works with all Point I/O modules
• Requires 24V DC SELV/PELV power supply
• Connects to DeviceNet networks
• Supports I/O and explicit messaging

Frequently Asked Questions

• Q1: What is the dual role of the 1734-ADNX adapter?
• A1: The 1734-ADNX acts as both a scanner/master for Point I/O modules and a slave device for DeviceNet masters.
• Q2: What is the Auto Catalog Replace feature?
• A2: This feature automatically corrects errors when identical modules are removed and replaced in wrong locations.
• Q3: What power supply is required for this adapter?
• A3: It requires a 24V DC Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV) power supply.
• Q4: Where is this adapter installed in the system?
• A4: The 1734-ADNX is a starter module that mounts on the left side of the Point I/O system.
• Q5: How many status indicators does it have?
• A5: It has 3 red/green status indicators and 2 green power supply indicators for easy troubleshooting.
