Description
Allen-Bradley ArmorStart LT 291D-FBZ-G2-3FR Distributed Motor Controller
Product Overview
This ArmorStart LT controller mounts directly on the machine.
It reduces wiring time.
It improves motor control reliability.
Key Value Highlights
- On-machine motor starting solution
- Supports forward and reverse control
- Strong enclosure for harsh areas
- Fast installation and easy service
- Built-in diagnostics and status LEDs
Motor Control Capability
- Starting method
- Full-voltage motor starting
- Reversing operation supported
- Motor size range
- 0.5 to 5 Hp
- 0.37 to 3 kW
- Application
- Three-phase motors
Network & Control Features
- Communication options
- DeviceNet
- EtherNet/IP compatible versions
- Local control
- DeviceLogix embedded logic
- Peer-to-peer messaging support
- Status feedback
- LED diagnostics
- Fault and run indication
Catalog Number Structure
- 291D
- Reversing starter series
- -FBZ
- IP66 / UL Type 4/12 enclosure
- Overload range 1.1 to 7.6 A
- External 24 V DC control power
- -G2
- ArmorConnect power and motor interface
- -3FR
- Hand / Off / Auto keypad
- Forward / Reverse selector
Electrical Performance
- Operating voltage
- 400Y/230 to 480Y/277 VAC
- Frequency
- 50 / 60 Hz
- Impulse withstand
- 4 kV
- Overload protection
- Automatic or manual reset
- Adjustable trip settings
Power Supply Design
- Internal supply
- 50 W integrated 24 V DC source
- External supply range
- 19.2 to 26.4 V DC
- Inrush current
- Less than 10 A for 35 ms
Environmental Durability
- Operating temperature
- -20 to +50 °C
- Storage temperature
- -25 to +85 °C
- Ingress protection
- IP66 / UL Type 4 / 12
- Humidity resistance
- Up to 95% non-condensing
Shipping & Warranty
- Warranty period: 12 months
- Shipping methods: FedEx, UPS, DHL
