Description
Allen-Bradley 1771-CE I/O Chassis Cable | PLC-5 Series Connectivity
The Allen-Bradley 1771-CE provides a specialized connection solution for industrial automation systems. This robust cable links your 1771-P2 power supply to PLC-5 series chassis with reliable performance. Its compact design ensures easy installation in control panels and industrial enclosures.
Technical Specifications
- Manufacturer: Allen-Bradley
- Model Number: 1771-CE
- Series Compatibility: PLC-5
- Cable Type: I/O Chassis Connection Cable
- Length: 1 Foot (0.3 Meters)
- Connector Gender: Male and Female Plug
- Pin Configuration: 9-Pin Design
- Voltage Rating: 250V AC Maximum
- Current Capacity: 5A Per Contact
- Insulation Resistance: 1000 MΩ Minimum
- Dielectric Strength: 1500V AC for 1 Minute
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Humidity Range: 5% to 95% Non-Condensing
- Frequency Rating: 50-60 Hz
- Weight: 1.06 lbs (0.48 kg)
- Flammability Rating: UL94 V-0
Warranty Information
- This product includes 12-month coverage against defects
- Warranty covers replacement for faults
- Protection applies under normal operating conditions
- Quick resolution process for validated claims
Frequently Asked Questions
- Q: Can I use the 1771-CE cable with other power supplies?
A: This cable specifically designed for use with the 1771-P2 power supply only - Q: What is the maximum voltage rating for this cable?
A: The cable handles up to 250V AC between contacts - Q: Does this cable require special handling during installation?
A: No special handling needed beyond standard ESD precautions - Q: Can I use multiple 1771-CE cables in sequence?
A: We recommend direct connection without daisy-chaining cables - Q: What maintenance does this cable require?
A: The cable needs periodic inspection for physical damage or corrosion
Comparison Products
Explore other Allen-Bradley components: 1771-IGD Module and 1771-IL Input Card.
