Bently Nevada 3300 XL 11 mm Probe 330709-000-120-10-02-00

Description

Brief Introduction

The 3300 XL 11 mm Proximity Probes from Bently Nevada measure shaft vibration and position accurately. Model 330709-000-120-10-02-00 has a M16 x 1.5 thread without armor. It works well in tight spaces. This unit is new and original. We offer a 12-month factory warranty. Made in U.S.A.

Technical Specifications

• Brand: Bently Nevada
• Model: 330709
• Series: 3300 XL 11 mm
• Thread Size: M16 x 1.5 (no armor)
• Unthreaded Length: 0 mm
• Overall Case Length: 120 mm
• Total Probe Length: 1.0 meter (3.3 feet)
• Connector: Miniature coaxial ClickLoc, standard cable
• Agency Approval: Not required (Option 00)
• DC Resistance (RPROBE): 5.9 ± 0.5 ohms
• Target Flat Surface Diameter (min): 30.5 mm
• Shaft Diameter (min recommended): 152 mm
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 304 stainless steel
• Cable Type: 75 Ω triaxial, FEP insulated
• 60 Hz Magnetic Field Rejection:
  • At 0.5 mm gap: 0.001 V pp/gauss
  • At 2.5 mm gap: 0.009 V pp/gauss
  • At 4.6 mm gap: 0.027 V pp/gauss
• Operating & Storage Temperature: -52°C to +177°C
• Storage Temperature Only: -52°C to +105°C
• Relative Humidity: 100% condensing (nonsubmersible)
• Probe Case Torque (Max): 63.3 N•m
• Probe Case Torque (Recommended): 21.1 N•m
• Connector Torque: Finger tight max 0.565 N•m
• Minimum Bend Radius: 25.4 mm
• Max Thread Engagement: 24 mm

Ordering Code Breakdown (Tree Structure)

• 330709 = 3300 XL 11 mm Probe, M16 x 1.5 thread, without armor
  • Unthreaded Length: 000 = 0 mm
  • Overall Case Length: 120 = 120 mm
  • Total Length: 10 = 1.0 meter
  • Connector/Cable: 02 = Mini coax ClickLoc, standard cable
  • Agency Approval: 00 = Not required

Installation & Maintenance

• Use recommended torque: 21.1 N•m. Never exceed 63.3 N•m.
• Tighten connector only by hand. Max torque 0.565 N•m.
• Keep bend radius larger than 25.4 mm to protect the cable.
• Do not use below -34°C. It may damage the pressure seal.
• ClickLoc connector locks securely without soldering.
• No special tools needed for routine cleaning.

Compatibility

• Works with Bently Nevada 3300 XL monitors and Proximitor sensors.
• Fits M16 x 1.5 mounting holes in machinery casings.
• Standard 75 Ω cable matches industrial vibration racks.

Environmental & Pressure Seal

• Tested to IEC 68-2-3 damp heat standard.
• Probe uses a Viton O-ring to seal differential pressure.
• Not pressure tested before shipment. Contact us for custom testing.

Packing List

• 1 x Bently Nevada 330709 probe assembly
• 1 x Factory calibration certificate
• 1 x Original packing box

Warranty & Shipping

• 12-month factory warranty against defects.
• We ship via FedEx, UPS, DHL. Tracking included worldwide.

Typical Applications & Diagnostic Ability

• Vibration monitoring on turbines, compressors, pumps
• Axial position control on large rotating shafts
• Detects imbalance, misalignment, bearing wear
• Resolution down to 0.001 mm for fine diagnostics

FAQ & Selection Guide

• Q: Can I use this probe without armor in abrasive areas?
• A: No. Choose armored version (model 330704) for abrasive or high-vibration environments.
• Q: What is the smallest shaft this probe can measure?
• A: Recommended minimum shaft diameter is 152 mm. Smaller shafts may cause cross-talk errors.
• Q: Why is the storage temperature lower than operating temp?
• A: Long-term storage above 105°C may degrade internal materials. Keep within -52°C to +105°C.
• Practical tip from field engineers:
• Always finger-tighten the ClickLoc connector. Over-tightening may break the connection.
• Selection guide:
• Pick option 00 (no armor) for clean, low-vibration areas like control rooms.
• Choose 1 meter total length for short runs inside the same cabinet.
• If ambient temperature stays below -34°C, add a heater or use a different probe model.
• Need agency approval? Select option 05 instead of 00.
