Description
Overview
The Bently Nevada 3300 XL 8 mm Proximity Probe (Model 330104-00-16-10-02-CN) is tailored for industrial applications requiring extended reach and regional compliance. Featuring a 160 mm stainless steel case (AISI 303/304) and country-specific certifications, this probe ensures adaptability to local regulatory standards. With a 1.0-meter armored cable and a ClickLoc connector, it guarantees secure signal transmission in high-vibration environments. Engineered for precision, the probe operates within a -17.5 Vdc to -26 Vdc range and maintains stability at altitudes up to 2000 meters, even under extreme temperature or mechanical stress.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330104-00-16-10-02-CN |
| Suffix Breakdown | – 00: 0 mm unthreaded length – 16: 160 mm case length – 10: 1.0 m cable – 02: ClickLoc connector (standard) – CN: Country-specific approval |
| Materials | Case: AISI 303/304 SST Tip: PPS Seal: Viton® O-ring |
| Electrical | Input Voltage: -17.5 to -26 Vdc Output Impedance: 50 Ω ±5% Transient Recovery: <3 ms Common-Mode Voltage Range: ±12 V |
| Mechanical | Cable Tensile Load: 200 N max Thread Engagement Depth: 15 mm Radial Vibration Tolerance: 25 g (10–2000 Hz) |
| Environmental | Operating Temperature: -40°C to +125°C Compliance: Regional safety standards (e.g., CCC, KC) Seismic Resistance: IEEE 693 compliant |
| Performance | Non-Linearity: ±0.6% FS Frequency Response: 0.5 Hz – 15 kHz (±1 dB) Warm-Up Drift: <0.05% FS |
Contact Information
For ESD/EMC test reports or custom packaging: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
