Description
Bently Nevada 3300 XL 8mm Reverse Mount Proximity Probe with FluidLoc Technology
Industrial-grade vibration sensor with hazardous area certifications and fluid-resistant cable for critical machinery monitoring.
Core Specifications
| Brand |
Bently Nevada |
| Complete Model |
330106-05-30-05-12-05 |
| Suffix Breakdown |
- 05: 0.5m cable length
- 30: Standard temperature cable
- 05: CSA/ATEX/IECEx approvals
- 12: FluidLoc connector system
- 05: Agency approval variant
|
| DC Resistance |
7.45Ω ±0.50 (0.5m cable) |
| Thread Size |
M10x1 (15mm max engagement) |
Technical Parameters
- Cable Length: 0.5 meter (1.6 feet)
- Weight Density: 323 g/m (11.4 oz/ft)
- Tensile Strength: 330N probe-to-lead, 270N connector point
- Humidity Performance: <3% ASF change at 93% RH (56 days)
- Seal Material: Viton® O-ring (differential pressure sealing)
Material Construction
| Probe Tip |
Polyphenylene sulfide (PPS) |
| Probe Body |
AISI 303/304 Stainless Steel |
| Connector |
Gold-plated brass/beryllium copper |
| Cable Insulation |
FEP (Standard) or PFA (Extended) |
Environmental Ratings
| Temperature Standard |
-52°C to +177°C (-62°F to +350°F) |
| Temperature Extended |
-52°C to +218°C tip (-62°F to +425°F) |
| Low Temp Warning |
Avoid below -34°C (-30°F) to prevent seal damage |
FluidLoc Connector Notes
- Sealed coaxial connector for fluid environments
- Typically not required with probe sleeves installed
- Evaluate application needs before selection
- Provides extra protection in immersion scenarios
Certifications & Approvals
- CSA safety certification
- ATEX explosion protection
- IECEx international standard
- IEC 68-2-3 humidity compliance
Packaging & Support
- Factory-sealed protective packaging
- 12-month manufacturer warranty
- Global shipping: FedEx, UPS, DHL options
