Bently Nevada 330707-00-20-90-11-00 | 9m Cable 11mm Proximity Probe

Description

Long-Reach 11mm Probe with 5/8-18 Thread

Introducing the Bently Nevada 330707-00-20-90-11-00. This is a long-cable 11 mm proximity probe from the 3300 XL series. It features a robust 5/8-18 UNF mounting thread and a protected connector. With a 9-meter cable, it is ideal for large machinery where the monitor is located far away.

Deciphering the Model Code

Product Family: 330707 (11mm Probe, 5/8-18 UNF, Unarmored)

Feature Selection Tree:

• ► -00- Unthreaded Length: 0.0 inch
• ► -20- Case Length: 2.0 inch Body
• ► -90- Cable: 9.0 meter Long Length
• ► -11- Connector: ClickLoc with Protector
• ► -00 Approvals: Standard Version

Why Choose This Model?

• Extended Reach: The 9-meter cable allows installation on large turbines, compressors, or fans where the monitoring panel is distant.
• Protected Connection: The connector protector (-11-) shields the vital electrical connection from impact and contamination.
• Heavy-Duty Thread: The 5/8-18 UNF thread offers a secure mount in demanding applications.
• Wide Temperature Range: Operates reliably from -51°C to +177°C.
• System Integration: A core component of the 3300 XL 11 mm Proximity Probes monitoring system.

Technical Specifications

• Product Identification
  • Brand: Bently Nevada
  • Model: 330707-00-20-90-11-00
  • Type: 11mm Vibration Probe
• Electrical Data
  • Resistance (9m): 8.5 ± 1.1 ohms
  • Cable Type: 75 Ω Triaxial, FEP Insulation
• Mechanical Data
  • Mounting: 5/8-18 UNF Thread
  • Torque (Recommended): 15.2 N•m
  • Connector: Hand-tighten only
  • Min. Bend Radius: 25.4 mm
• Construction Materials
  • Tip: PPS Plastic
  • Case: 304 Stainless Steel
  • Cable: FluidLoc Jacket
• Environmental Ratings
  • Operating Temp: -51°C to +177°C
  • Note: Avoid below -34°C for pressure seal life.

Simple Installation Guide

• Clean the 5/8-18 UNF threaded hole.
• Insert and hand-tighten the probe.
• Use a torque wrench. Tighten to 15.2 N•m.
• Connect the cable. Push the ClickLoc connector until it clicks.
• Route the long cable carefully. Avoid sharp bends and pinch points.

Customer Support & Ordering

• Warranty: All products include a 12-month warranty.
• Global Shipping: Fast delivery via FedEx, UPS, and DHL.
• Compatibility: Works with Bently Nevada 3300/3500 systems.
• Questions? Chat with us on WhatsApp: +86 158 8020 0923.

Professional FAQs

Cable & Length Selection

• Q: Why does the 9-meter probe have a higher resistance (8.5 ohms) than the 1-meter version (5.9 ohms)?
• A: The longer cable has more internal wire. This adds to the total electrical resistance measured from the tip to the connector. The monitoring system is calibrated to expect this value based on cable length.
• Q: Can I coil up the extra length if I don’t need the full 9 meters?
• A> Yes, but coiling must be done properly. Make large, loose coils (at least 12 inches in diameter). Do not make tight coils or kink the cable, as this can damage the internal wires.

Product Features

• Q: What is the advantage of a shorter 2.0-inch case length?
• A: A shorter case length is useful in applications with limited space behind the mounting point. It provides a more compact installation profile.
• Q: Is the FluidLoc cable suitable for outdoor use?
• A> Yes. The FluidLoc jacket is resistant to moisture, oils, and many chemicals. However, for direct burial or constant submersion, additional conduit or protection is recommended.

Practical Installation Tip

• Q: What is a key pre-installation check for the 5/8-18 thread?
• A> Always verify the tap depth and thread condition in your mounting hole. A damaged or shallow thread can prevent the probe from reaching the proper seating depth, affecting the measurement gap and potentially causing mechanical failure.
