Bently Nevada 330904-08-15-05-02-00 Nsv Proximity Probe

Description

Bently Nevada 330904-08-15-05-02-00 NSv Proximity Probe

New original condition proximity probe for precision vibration monitoring. Features enhanced chemical resistance and superior performance in harsh industrial environments.

Complete Model Suffix Breakdown

• 330904: 3300 NSv Probe, M8X1 thread, armored
• -08-: 80 mm unthreaded length
• -15-: 150 mm overall case length
• -05-: 0.5 meter cable (20 inches)
• -02-: Miniature coaxial ClickLoc connector
• -00-: No agency approval required

Key Technical Specifications

• Brand: Bently Nevada
• Model: 330904-08-15-05-02-00
• Linear Range: 0.25-1.75mm (10-70 mils)
• Sensitivity: 7.87 V/mm ±20%
• Frequency Response: 0-10 kHz (±3dB)
• Operating Temp: -52°C to +177°C
• Probe Resistance: 4.0Ω ±0.5 (0.5m cable)
• Housing: AISI 304 stainless steel
• Tip Material: Chemical-resistant PPS

Installation Guide

• Recommended Gap: 1.0 mm (40 mils)
• Max Torque: 5.1 N•m (45 in•lb)
• Thread Engagement: ≤12mm for M8x1
• Min Target Size: 13mm diameter

Environmental Durability

• Stainless steel armor protection
• Viton O-ring pressure seal
• 25.4mm minimum bend radius
• Enhanced chemical resistance

Compatibility & Maintenance

• Fully compatible with 3300 RAM probe systems
• Mechanically/electrically interchangeable
• Superior side-view characteristics
• No recalibration needed when replacing

Package & Warranty

• 12-month warranty
• New in original factory packaging
• Worldwide shipping: FedEx/UPS/DHL

Diagnostic Capabilities

• Shaft vibration analysis
• Radial position monitoring
• Thrust position detection
• Bearing wear diagnostics

Frequently Asked Questions

• Q: Chemical resistance vs RAM probes?
  A: Enhanced for process applications
• Q: Minimum target size?
  A: 8.9mm diameter (13mm recommended)
• Q: Pressure testing included?
  A: No – contact for custom tests
