Bently Nevada 3300 NSv Proximity Probe – New & Original (P/N: 330904-00-10-05-11-05)
???? Description
New factory-sealed 3300 NSv vibration probe with 12-month warranty. Features M8x1 threaded stainless steel case, armored FluidLoc® cable, and chemical-resistant design. Compatible with 3300 RAM systems. Ships via FedEx/UPS/DHL.
⚙️ Technical Data
Brand: Bently Nevada
Model: 3300 NSv Probe
Full P/N: 330904-00-10-05-11-05
(Breakdown: M8x1/Armored • 0mm Unthreaded • 100mm Case • 0.5m Cable • ClickLoc Connector • Multi-Cert)
- Range: 1.5mm (60 mils) linear range
- Accuracy: ±0.06mm deviation
- Output: -1 to -13V DC (7.87V/mm scale factor)
- Temp Range: -52°C to +177°C (-62°F to +351°F)
- Resistance: 4.0Ω ±0.5 (0.5m cable)
- Target Size: Min 8.9mm Ø (13mm recommended)
???? Compatibility
Direct replacement for 3300 RAM probes. Superior chemical resistance and side-view performance vs 3000-series probes. Works with standard 75Ω coaxial systems.
???? Packaging & Warranty
Includes: 1x Probe with connector protector • Factory documentation
12-month warranty • Original sealed packaging
???? Installation Guide
- Gap Setting: 1.0mm (40 mils) optimal
- Torque: 5.1 N•m max (finger tight + ¼ turn)
- Bend Radius: >25.4mm (1.0in)
- Wiring: Max 305m shielded triad cable
Agency Approvals
Multiple international certifications (Option 05)
Shipping
FedEx • UPS • DHL | Global express options available
❓ FAQ
Q: Cable length options?
A: 0.5m (this model), 1m, 5m or 7m
Q: Pressure rating?
A: Viton® O-ring seal (contact for pressure testing)
Q: Chemical resistance?
A: Superior to 3300 RAM probes for compressor applications
