Description
Bently Nevada 3300 NSv Reverse Mount Probe with China-Specific Approvals
Product Configuration
This specialized 330907-05-30-70-12-CN model features 7.0m FluidLoc cable with China-specific certifications. Designed for reverse-mount installations in Chinese industrial facilities requiring M10X1 threading.
Complete Suffix Analysis
- 330907: NSv Probe Series
- 05: M10X1 Thread Standard
- 30: Standard Configuration
- 70: 7.0 Meter Cable
- 12: FluidLoc Cable with ClickLoc
- CN: China-Specific Approvals
Technical Parameters
- DC Resistance: 5.9 ± 0.9 Ω @ 7m
- Voltage Output: -1 to -13 Vdc
- Temperature Range: -52°C to +177°C
- Pressure Seal: Viton O-ring
- Weight Range: 14-150g
- Thread Engagement: Max 15mm
- Probe Tip Material: PPS Polymer
Installation Specifications
- Optimal Target Gap: 1.0mm (40 mils)
- Max Installation Torque: 7.5 N•m
- Wiring Specification: Shielded triad cable (0.2-1.5 mm²)
- Max Run Length: 305m to monitor
- Critical Temp Note: Avoid sustained exposure below -34°C
What’s Included
- Complete probe assembly
- Installation documentation
- 12-month warranty card
Global Shipping
Available via FedEx, UPS, or DHL express services
Technical Questions
- Q: What’s different about CN approvals?
A: Meets specific Chinese regulatory standards for industrial equipment - Q: Can this probe be used outside China?
A: Yes, but may require additional certifications for other regions - Q: Is the FluidLoc cable oil-resistant?
A: Yes, specially designed for oil and chemical exposure
Similar Models Comparison
| Model Number | Cable Length | Connector Type | Approvals | Purchase Link |
|---|---|---|---|---|
| 330907-05-30-05-12-05 | 0.5m | FluidLoc | Multiple | View Product |
| 330907-05-30-05-12-00 | 0.5m | FluidLoc | Standard | View Product |
| This Model: 330907-05-30-70-12-CN | 7.0m | FluidLoc | China-Specific | – |
