Allen-Bradley 1746-OB32: 32-Channel 24VDC Digital Output Module
Boost your SLC 500 system’s capabilities with the high-density Allen-Bradley 1746-OB32 DC output module. This module provides thirty-two 24VDC output channels to control a wide array of devices like solenoids, pilots lamps, and motors. It is designed for easy installation in any compatible SLC 500 chassis, offering reliable performance for industrial automation applications.
Technical Specifications
Here are the key technical details for the 1746-OB32 module:
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1746-OB32 (Complete Suffix Information)
- Module Type: Digital DC Output Module
- Output Channels: 32 Points
- Voltage Range: 5-50 VDC
- Nominal Output: 24 VDC
- Current per Point: 0.5 A
- Current per Common: 2 A
- Total Module Current: 8 A
- On-State Delay: 0.1 ms
- Off-State Delay: 1.0 ms
- Backplane Current: 190 mA @ 5V
- Operating Temperature: 0 to 60 °C (32 to 140 °F)
Installation & Compatibility
This module can be installed in any slot (except slot 0) of a 1746 SLC 500 fixed or modular chassis. For best wiring practices, use Allen-Bradley 1492 interface systems. This ensures proper wire size, prevents over-crowding, and allows the door to close securely.
Package Contents & Warranty
Your purchase includes:
- One (1) 1746-OB32 Output Module
- One (1) Removable Terminal Block (RTB)
- One (1) Label Sheet
This product is backed by a 12-month warranty.
Shipping Information
We ship worldwide via reliable carriers: FedEx, UPS, and DHL.
Download Manual
For detailed wiring diagrams and full specifications, please download the product manual here: Download Datasheet.
