Allen-Bradley 1756-OF8I: Precision Isolated Analog Output Module
Experience superior control with the 1756-OF8I analog output module. This high-performance module delivers 8 fully isolated channels with exceptional accuracy. It provides both voltage and current outputs for versatile applications. Perfect for precise process control systems.
Need detailed precision specifications? Download our complete technical guide:
Technical Specifications
Brand & Model: Allen-Bradley 1756-OF8I
Type: 8-Channel Isolated Analog Output
Voltage Outputs: -10 to +10V, 0-10V, 0-5V
Current Outputs: 0-20mA, 4-20mA
Resolution: 16-bit high precision
Accuracy: 0.05% calibration accuracy
Isolation: 250V between channels/backplane
Update Rate: 1ms module scan time
Protection: ±30V DC overvoltage protection
Backplane Power: 5.1V @ 200mA, 24V @ 275mA
Power Dissipation: 6.5 Watts maximum
Terminal Blocks: 1756-TBNH, 1756-TBSH
Operating Temp: 0°C to 60°C
Data Format: IEEE 32-bit floating point
