Discrete Output Module 140DAO84000 Schneider Electric Buy Now

Description

Schneider Electric 140DAO84000 Discrete Output Module

Electrical Specifications

• Brand: Schneider Electric
• Model: 140DAO84000
• Output Type: Isolated AC channels
• Voltage Range: 20-253V AC
• Max Load: 4A per channel
• Response Time: ≤0.5 ms

Robust Performance

• Surge Capacity: 30A (1 cycle)
• Bus Current: 350 mA
• Voltage Withstand: 400V for 1 cycle
• Protection: RC filter on all outputs

Physical Details

• Dimensions: 12.3″ L × 1.8″ W × 6.4″ H
• Weight: 1.069 lb (0.485 kg)
• Mounting: Quantum rack compatible
• Terminals: Screw-clamp connectors

Environmental Ratings

• Operating Temp: 32°F to 140°F
• Altitude: 16,400 ft max
• Humidity: 95% non-condensing
• Vibration: 5g @ 10-150 Hz

Package Contents

• 1x Output Module
• Mounting hardware
• Installation guide

Global Shipping

FedEx | UPS | DHL – Delivers in 3-7 business days

Installation Steps

1. Mount in Quantum rack
2. Connect 24V DC power
3. Wire loads to terminal blocks

Maintenance Guide

• Check terminal tightness annually
• Verify voltage drop <1.5V
• Clean vents quarterly

Technical Support

Q: Minimum load current?
A: 1 mA at 24V AC (off-state leakage)

Q: Compatible with DC loads?
A: No – AC output only

Q: Redundancy options?
A: Use hot standby modules

Q: Warranty period?
A: 12 months manufacturing defects
