Emerson VE4006P2 DeltaV M-Series Serial Interface Card | Dual Port Communication Module

Description

VE4006P2 | DeltaV M-Series Serial Interface

• Brand: Emerson
• Series: DeltaV M-Series
• Model: VE4006P2
• Type: Serial Interface Card
• Ports: 2 Independent Channels
• Warranty: 12 Months

VE4006P2 is used for stable serial communication.
It links PLC and field devices with safe isolation.

Communication Capability

• Supported Modes:
  • RS232
  • RS422/485 Half Duplex
  • RS422/485 Full Duplex
• Baud Rate: 300 to 115200 bps
• Data Bits: 7 or 8
• Stop Bits: 1 or 2
• Parity: Even / Odd / None
• Ports Isolated: Yes
• External Grounding Required

Advanced Control Settings

• Message Timeout: 100–25,500 ms
• Retry Count: 0–255
• Transmit Delay: 0–25,500 ms
• Delay Step: 100 ms
• Error Detection: Built-in
• Noise Immunity: Industrial Level

Environmental Strength

• Operating Temp: -40°C to 70°C
• Storage Temp: -40°C to 85°C
• Humidity: 5–95% Non-Condensing
• Air Class: ISA-S71.04 Class G3
• Vibration: 3mm (5–13Hz), 0.5g (13–150Hz)
• Shock: 10g, 11ms
• Protection: IP20

Configuration Breakdown

• VE4006P2
  • Port Layer
    • Channel A → Isolated
    • Channel B → Isolated
  • Protocol Layer
    • RS232 Standard
    • RS422/485 Flexible Mode
  • Timing Layer
    • Adjustable Timeout
    • Retry Control
    • Delay Setup
  • Protection Layer
    • Port-to-Port Isolation
    • System Isolation
    • Ground Shield Design

Main Advantages

• Wide baud rate range
• Dual independent ports
• Strong isolation safety
• Works in cold and hot areas
• Flexible communication setup
• High retry support for long lines
• Stable in dusty air class G3

Warranty & Shipping

• 12-Month Warranty
• Fully Tested Before Shipment
• Courier: FedEx / UPS / DHL
• Fast Worldwide Delivery

Contact:
+86 158 8020 0923

Professional FAQ

1. Can VE4006P2 connect to old RS232 devices?

Yes. It supports low baud rates like 300 bps for legacy devices.

2. When should I use RS485 mode?

Use RS485 for long distance or multi-drop networks.

3. What is a common setup mistake?

Wrong grounding. Always connect external ground to avoid noise.

4. How to improve communication stability?

Set proper timeout and retry count for your network length.

5. Is it good for harsh plants?

Yes. It works in -40°C to 70°C and air class G3 areas.
