Description
GE Fanuc IC693CPU323 Embedded CPU Baseplate: Compact PLC Control
Core Features
All-in-one 10-slot PLC baseplate with embedded 80188 CPU (10MHz). Delivers 0.6ms/K logic scan for small-scale automation. Includes serial port for SNP protocols.
Technical Specifications
| Brand | GE Fanuc |
| Model | IC693CPU323 |
| Series | Series 90-30 |
| CPU | 80188 @ 10MHz |
| Memory | 12Kbytes user program |
| Slots | 10 I/O + 1 power supply |
| Scan Rate | 0.6ms per 1K logic |
| Power | 5V DC, 430mA |
I/O Capacity
- 320 discrete I/O points
- 64 analog input words
- 32 analog output words
- 340 timers/counters
Installation Notes
- Panel-mount via baseplate holes
- No expansion capability
- Power supply hosts backup battery
Communication
- 1 serial port (SNP/SNP-X slave)
- Optional modules: Ethernet, Profibus
- No built-in clock/override functions
Environmental Ratings
- Operating temp: 0°C to 60°C
- Storage temp: -40°C to 85°C
- 5-95% non-condensing humidity
Package Contents
- IC693CPU323 Baseplate
- Mounting hardware
Shipping Options
FedEx | UPS | DHL | Express Air
FAQ
Q: Expansion possible?
A: No expansion or remote racks
Q: Real-time clock?
A: No battery-backed clock
Q: Supported memory?
A> RAM with battery backup + optional EPROM/EEPROM
Q: Compatible modules?
A: Standard Series 90-30 I/O (excludes PCM/CCM)
