Description
Product Overview
- GE IS420UCSCH1B is a UCSC standalone controller.
- Part of the Mark VIeS Functional Safety System.
- Full name: UCSC Gateway Stand-Alone Controller.
- Manufactured by GE Vernova.
- Assembled in the USA.
Model Number Breakdown
- IS420UCSCH1B
- IS420 = Mark VIe Series assembly
- UCSC = Functional product acronym (UCSC Gateway)
- H = Group one Mark VIeS Series grouping
- 1 = Conformal PCB coating type
- B = B-rated functional product revision
Key Technical Specifications
- Brand: GE Vernova (General Electric)
- Series: Mark VIeS / Mark VIe
- Part number: IS420UCSCH1B
- Product type: Quad core controller
- CPU frequency: 1.2 GHz
- CPU cores: 4
- Memory: 2 GB DDR3-1066 SDRAM with ECC
- NVSRAM: 3067 variables, 64 totalizers, 338 forces
- Operating system: QNX Neutrino 6.5 or 7.1
- Cooling: Convection
- Orientation: Vertical only
Dimensions and Weight
- Height: 8.03 inches (204 mm)
- Depth: 5.99 inches (152 mm)
- Width: 2.17 inches (55 mm)
- Weight: 1,327 grams (2.93 lbs)
Environmental Limits
- Normal altitude: 0 to 1000 meters (101.3 to 89.9 kPa)
- Storage temperature: -40°C to +85°C (-40°F to +185°F)
- Operating temperature: 40°C to 70°C
- Convection cooling requires proper cabinet ventilation.
Ethernet Ports and Connectivity
- Total Ethernet ports: 6
- 5 ports on front panel
- 1 port on bottom for Predix connectivity
- 3 IONet ports (R/S/T) for I/O module communications
- Supports simplex, dual, TMR, and shared I/O
- ENET 1: EGD/UDH to ToolboxST, HMI, safety controller, PACSystems
- ENET 2: Secondary UDH, Modbus TCP slave, OPC UA
Platform Features
- EFA (Embedded Field Agent) for Predix cloud apps
- Embedded EtherCAT for fast automation control
- Embedded PPNG for Predix notification gateway
- Real-time hypervisor technology
- QNX Neutrino multi-task OS for high reliability
Ports on Module
- 5 Ethernet ports (front panel)
- 1 Predix Ethernet port (bottom)
- 2 USB ports for UDH setup and restore
- 1 COM port (RJ45, 115200 bit/s, 8N1, GE troubleshooting)
- 1 Display Port (disabled after startup)
- 1 microSD port (not supported)
Redundancy Support
- Simplex configuration
- Dual configuration (uses S/SL2 and R/SL1 ports)
- TMR configuration (uses all three ports R/S/T)
- No single point of failure during maintenance shutdowns.
IONet Communication
- Private Ethernet for Mark VIe I/O packs only.
- Uses IEEE 1588 for clock sync within 100 microseconds.
- This controller does NOT host application I/O on backplane.
- External data moves to/from control database via IONet.
Software and HMI
- HMI: ControlST V07.00.00C or later
- ToolboxST on 4 GB unencrypted flash drive for config
- Default IP address: 192.168.101.111
- Configure UDH IP for site HMI communication.
Virtual Network
- EFA and Mark VIe control run as separate virtual machines.
- Hypervisor virtual network connects both VMs.
- EFA connects to cloud via physically managed switch.
- Switch separates Mark VIe control from cloud for security.
Diagnostic Features
- System limit checking (software) for analog inputs
- High/low hardware limit checking
- Two occurrences needed before alarm triggers
- Diagnostic messages in Control System Toolbox
- Each card has composite logic output for faults
Power and Protection
- Power supply voltage: 28 V dc
- Voltage range: 18 to 32 VDC
- Surge protection: 4A 125V dc fuse (non-replaceable)
- Nominal melting: 26 A² seconds
Installation Guide
- Mount in environmentally controlled room or control room.
- Floor surface must be flat, level, and continuous.
- Customer provides mounting hardware.
- Use lifting lugs with cables within 45° of vertical.
- Seal conduits to access plates for convection cooling.
- Follow cable separation rules to avoid electrical noise.
Cable Separation and Routing
- Different voltages can cause electrical noise.
- Noise disrupts microprocessor control systems.
- Follow manufacturer cable installation guidelines.
- Use level rules during system planning.
- Proper separation ensures trouble-free operation.
Compatibility
- Works with Mark VIe I/O packs and controllers only.
- Compatible with GE PACSystems products via ENET1.
- Supports Modbus TCP slave (read/write).
- Use with Versamax series requires additional gateway.
Warranty
- 12 months warranty from delivery date.
- Covers manufacturing defects only.
Shipping
- Carriers: FedEx, UPS, DHL.
- Express shipping worldwide.
- Tracking number within 24 hours.
Typical Applications
- Gas and steam turbine control
- Balance of plant (BoP) controller
- High-speed industrial automation
- Predix cloud-connected systems
- Functional safety applications (Mark VIeS)
Frequently Asked Questions
- Does this controller have onboard I/O?
- No, IS420UCSCH1B does NOT host any I/O.
- All I/O connects through IONet ports to external packs.
- What is the default IP address?
- Default IP is 192.168.101.111.
- Change it via ToolboxST for your site network.
- Controller not communicating. Where to start?
- Check power supply voltage (18-32 VDC).
- Verify Ethernet cable connections to correct ports.
- Use ToolboxST to test UDH network configuration.
- Can I use this in a TMR safety system?
- Yes, IS420UCSCH1B supports TMR redundancy.
- Use all three IONet ports (R/S/T) for TMR.
- Part of Mark VIeS functional safety family.
- 选购指导 (Selection Guide)
- Choose IS420UCSCH1B for Mark VIeS safety systems.
- Select this model when you need UCSC gateway functions.
- Pick quad core version for high-speed processing.
- Verify redundancy needs (simplex, dual, or TMR).
- Check if Predix cloud connectivity is required.
- For non-safety applications, consider standard Mark VIe controllers.
