Description
Product Overview
The HIMA F3236 is a 16-fold input module for safety applications. It works with 1-signal sensors or mechanical contacts. The module provides safety isolation for each channel. It meets requirement class AK 1 to 6. The module runs automatic self-tests during operation. Consequently, you get high reliability without manual checks.
Key Features
16 input channels for safety signals
Safety isolation on every channel
Requirement class AK 1 through 6
Full automatic self-test during operation
Works with 6 mA current or 24 V mechanical contacts
Typical switching time of only 8 ms
Technical Specifications
Parameter Value
Brand HIMA
Model F3236
Type 16-fold safety input module
Number of inputs 16 channels
Signal type 1-signal, 6 mA (with cable plug)
Alternative input Mechanical contact, 24 V DC
Switching time 8 ms (typical)
Safety class AK 1 to 6
Isolation Safety isolation per channel
Space requirement 4 TE
Operating voltage 5V DC 120 mA
Operating voltage 24V DC 200 mA
Self-test features Cross-talking with walking-zero
Self-test features Filter capacitor check
Self-test features Full module function test
Automatic Self-Test Functions
Cross-talking test using walking-zero pattern
Filter capacitor function verification
Complete module function validation
Tests run automatically without stopping operations
No need for external test equipment
Installation Guide
Fits 4 TE wide rack slot
Insert module into compatible HIMA backplane
Connect sensors to any of the 16 input channels
Use shielded cables for noisy environments
No special tools required for mounting
Allow space for wiring access
Commissioning & Maintenance
Module self-tests start automatically on power-up
LED indicators show channel status
No routine calibration needed
Walking-zero test runs continuously
Replace module if self-test fails repeatedly
Firmware updates not applicable for this model
Compatibility Notes
Works with all HIMA safety systems AK1 to AK6
Compatible with 6 mA current sourcing sensors
Also works with standard 24 V DC mechanical contacts
For reference, check similar modules like Versamax for other applications
Not compatible with analog signals or thermocouples
Typical Applications
Emergency stop monitoring in factories
Safety door position detection
Light curtain signal collection
Pressure switch monitoring in process plants
Temperature switch inputs for burners
Frequently Asked Questions (FAQ)
What does AK 1 to 6 mean?
AK stands for requirement class in safety standards. AK1 is lowest safety level. AK6 is highest safety level for this module.
Can I mix 6 mA and 24 V inputs on the same module?
Yes, you can. Each channel works independently. However, all channels share the same return path.
How do I know if the self-test finds a fault?
The module sets a system fault flag. HIMA CPU reads this flag. Then the system goes to safe state.
What is walking-zero test?
Walking-zero sends a zero signal to each input one by one. This test checks for cross-talk between channels. Consequently, it verifies isolation integrity.
My module fails self-test occasionally. What should I do?
First, check your power supply voltages. Then verify all field wiring. If problem persists, replace the module.
Experience-based tip:
Always use separate shielded cables for each group of 8 inputs. This reduces cross-talk in noisy environments. For very high noise areas, use optical isolation externally.
Which shipping method do you recommend?
We ship via FedEx, UPS, or DHL. All methods include tracking. Delivery takes 3 to 7 business days worldwide.
What warranty do you provide?
We offer 12-month warranty against defects. This covers manufacturing faults only. It does not cover damage from wrong wiring or overvoltage.
Can I use this module with non-HIMA systems?
No, you cannot. This module requires a HIMA backplane and HIMA CPU for safety functions.
Packing List
One HIMA F3236 input module
No cables or connectors included
No documentation included (digital download available)
