Description
GE Fanuc IC693MDL330 AC Output Module – Industrial-Grade Reliability
Premium 8-point AC output module for GE Series 90-30 PLC systems. Designed for heavy-duty industrial environments with 2 isolated groups supporting separate AC phases. Controls incandescent/inductive loads with 20A inrush capacity and built-in transient protection. Features real-time status LEDs and fused protection.
TECHNICAL SPECIFICATIONS
| Brand | GE Intelligent Platforms/GE Fanuc |
| Model | IC693MDL330 (Full Suffix: IC693MDL330Â) |
| Series | Series 90-30 |
| Output Type | AC Relay |
| Voltage Range | 85-264V AC |
| Current Rating | 2A per point (4A per group) |
| Output Points | 8 (2 isolated groups of 4) |
| Isolation | 1500V field-to-logic |
| Inrush Current | 20A max per cycle |
| Operating Temp | 0°C to 60°C |
| Frequency | 50/60 Hz |
INSTALLATION & COMPATIBILITY
• Mounts in Series 90-30 PLC racks
• Requires 120-240V AC power source
• Not compatible with DC power systems
• Group wiring: 4 outputs share 1 common
PACKAGE INCLUDES
• (1) IC693MDL330 Output Module
• Installation manual
SHIPPING & WARRANTY
• Ships in 24hr via FedEx/UPS/DHL
• 12-month warranty from delivery date
FREQUENTLY ASKED QUESTIONS
Q: Can both groups use same power supply?
A: Yes. Commons are isolated but can share source.
Q: Minimum load required?
A: 100mA minimum per output.
Q: LED indicators explained?
A: Green LEDs (A1-A8) show output status. Red “F” LED indicates blown fuse.
