IC693MDL340 GE Fanuc – Discrete Output Module Series 90-30

Description

GE Fanuc IC693MDL340: 16-Channel 120VAC Output Module (Discontinued – New Stock)

Core Functionality

Discrete output module for Series 90-30 PLC systems. Controls 16 AC loads (relays, lamps, solenoids) with 0.5A per channel. Features dual isolated groups for flexible phase wiring.

Technical Specifications

• Brand/Model: GE Fanuc IC693MDL340 (Emerson)
• Output Voltage: 85-132V AC (120VAC nominal)
• Current Capacity: 0.5A per point, 3A per group
• Isolation: 1500V logic/field, 500V between groups
• Response Time: 1ms ON, ½ cycle OFF
• Backplane Draw: 315mA @ full load
• Protection: 3A fuse/group + RC snubber

Key Features

• Dual Isolated Groups: 8 channels/group with independent commons
• Visual Diagnostics: 16x green channel LEDs + red fuse alarm
• High Inrush Handling: 20A for 1 cycle (inductive loads)
• Low Leakage: <2mA @ 120VAC

Packaging & Warranty

• New original module in factory packaging
• Installation guide
• 12-month warranty

Shipping

Global express delivery via FedEx, UPS, or DHL. In-stock ready to ship.

FAQ

Q: Is this module discontinued?
A: Yes, but we supply new factory-sealed stock with full warranty.

Q: Minimum load requirement?
A: 50mA per channel to ensure proper operation.

Q: Can groups share a power supply?
A: Yes – commons can be jumpered for single-phase use.
