IC697MDL254 48V AC Input Module
DESCRIPTION
GE Fanuc’s IC697MDL254 delivers 32-point AC input control for Series 90-70 systems. Features 4 isolated groups (8 points each) supporting separate AC phases. Ideal for industrial sensors and switches with IEC Type 1 compatibility. Includes mechanical key security.
TECHNICAL DATA
| Brand | GE Fanuc |
| Model | IC697MDL254 |
| Series | Series 90-70 |
| Input Points | 32 (4 groups x 8) |
| Voltage | 48V AC |
| Input Current | 4.7 mA/point |
| Frequency Range | 47-63 Hz |
| Backplane Power | 0.30A @ 5V DC |
INSTALLATION GUIDE
- Verify power is OFF before wiring
- Connect AC source to all 4 isolated groups
- Use mechanical key to lock module position
- No DIP switches/jumpers needed
DIAGNOSTICS & MAINTENANCE
- Monitor all 32 points via LED status indicators
- Test group isolation quarterly
- Check for ≤2mA leakage current in off-state
- Clean terminals during maintenance
PACKAGING LIST
- IC697MDL254 Input Module
- Field-wiring terminal board
- Mounting hardware
SHIPPING METHODS
Global express shipping via FedEx, UPS, DHL
FAQ
Q: Can each group use different AC phases?
A: Yes! 4 isolated groups support separate phases.
Q: Works with 3-wire proximity sensors?
A: Yes. Compatible with 2-wire and 3-wire devices.
Q: How is module replacement prevented?
A: Mechanical keying blocks unauthorized changes.
