GE Fanuc IC697MDL752 12V DC 32-Point Output Module
Product Description
This high-speed DC output module for GE Series 90-70 PLCs delivers 32 points in 4 isolated groups. Designed for harsh industrial environments, it drives demanding loads with 1ms response time. Features VME bus compliance and tool-free installation. Perfect for complex machine control systems.
Technical Data
- Brand: GE Fanuc
- Model: IC697MDL752 (Series 90-70)
- Rated Voltage: 12V DC
- Output Range: 10-15V DC
- Outputs: 32 points (4 groups × 8 points)
- Current/Point: 0.5A continuous
- Current/Group: 2A max
- Response Time: 1ms (ON/OFF)
- Isolation: 1500V between groups
- Inrush Current: 10A (20ms max)
Installation Guide
- Insert into Series 90-70 rack (keyed alignment)
- Connect DC power (10-15V) and load devices
- Secure wires (AWG #14-#22) on terminal board
- Remove by pressing rear clips
Packaging & Shipping
- Includes: IC697MDL752 module, installation guide
- Global Shipping: FedEx, UPS, DHL (3-5 business days)
- Express Options: Next-day delivery available
FAQs
Q: Can it handle 24V DC loads?
A: No – operates only in 10-15V DC range.
Q: Maximum load per group?
A: 2A total across all 8 points in a group.
Q: Is it suitable for safety systems?
A: Yes – 1500V isolation protects critical circuits.
Q: Replacement fuse rating?
A: Built-in solid-state protection – no fuses needed.
