IC697MDL940 GE Fanuc Discrete Logic Output Module Series 90-70

Description

GE Fanuc IC697MDL940 Relay Output Module: Industrial-Grade Switching Solution

Description

Control low-to-medium power loads with precision using the GE Fanuc IC697MDL940. Designed for Series 90-70 PLC systems, this 16-point relay module features isolated Form C/A contacts with individual fuse protection. Ideal for switching relays, contactors, and indicator lamps in demanding industrial environments.

Technical Data

• Brand: GE Fanuc
• Model: IC697MDL940
• Output Type: 8 Form C (isolated) + 8 Form A (2 groups of 4)
• Switching Capacity: 2A per point
• Voltage Range: 5-265V AC/DC
• Isolation: 1500V output-to-backplane
• Response Time: ≤10 ms
• Contact Life: 100k cycles at rated load

Compatibility

Works with all GE Series 90-70 PLCs. Supports VME standard C.1 backplanes. Not compatible with Series 90-30 systems.

Packaging

Includes module unit only. No certificates included. Backed by 12-month manufacturer warranty.

Shipping

Global delivery via FedEx, UPS or DHL. Tracking provided.

FAQ

Q: Can it handle motor starter coils?
A: Yes, rated for inductive loads up to 2A at 20 cycles/minute.

Q: What protection is included?
A: Each point has 3A fuse + RC snubber (47Ω/0.015µF).

Q: Are status indicators visible?
A: Yes, per-point LEDs show ON/OFF state on logic side.
