Description
IC693MDL250: 16-Channel 120VAC PLC Input Module
Core Functionality
Connect high-voltage AC devices to your Series 90-30 PLC. This 120VAC input module handles 16 field devices with built-in noise protection.
Technical Specifications
| Brand | GE Fanuc |
| Model | IC693MDL250 |
| Input Type | 120VAC Isolated |
| Channels | 16 |
| Voltage Range | 0-132VAC |
| Frequency | 47-63Hz (50/60Hz) |
| On-State Voltage | 70-132VAC |
| Off-State Voltage | 0-20VAC |
| Isolation | 1500V RMS |
Installation Options
- Extended box-style terminal blocks
- Spring-style terminal blocks
- Standard box-style connectors
- Extended spring-style terminals
Compatible Systems
- GE Series 90-30 PLCs
- Industrial AC sensors and switches
- Multi-phase power systems
Package Contents
- 1x IC693MDL250 module
- Installation documentation
Warranty & Shipping
- 12-month performance warranty
- FedEx, UPS, DHL global delivery
FAQ
Q: What does the red band indicate?
A: High-voltage warning for safety.
Q: Can I change input filtering?
A: Yes, adjust during operation via program.
Q: What terminal blocks work?
A: Spring, box-style, and extended versions.
Q: How are terminals secured?
A: Green LED confirms proper locking.
