Keysight DSOX3014T 100 MHz Oscilloscope | 4 Ch Touch Screen

Description

Quick Overview

• Keysight DSOX3014T = 100 MHz, 4-channel oscilloscope.
• Part of InfiniiVision 3000T X-Series.
• Large 8.5-inch capacitive touch screen.
• Exclusive Zone touch triggering finds signals in seconds.

Key Features

• 100 MHz bandwidth, 4 analog channels.
• Update rate: 1,000,000 waveforms per second.
• Memory depth: 4 Mpts.
• Touch zone trigger – draw a box, scope triggers on that area.
• Fully upgradable: bandwidth, digital channels, AWG, DVM, serial decode.
• 8.5-inch capacitive touch screen works like a tablet.

Technical Specifications (Tree View)

• Basic Specs
  • Bandwidth: 100 MHz
  • Analog channels: 4
  • Update rate: 1,000,000 wfms/s
  • Memory: 4 Mpts
• Display & Interface
  • Screen: 8.5-inch capacitive touch
  • Languages: English, Chinese (simplified & traditional), Czech, French, German, Italian, Japanese, Korean, Portuguese, Russian, Spanish, Polish, Thai, Turkish
• Upgrade Options (buy anytime)
  • Higher bandwidth
  • 16 digital channels (mixed signal)
  • 20 MHz arbitrary waveform generator
  • 3-digit digital voltmeter
  • Serial trigger & decode (I2C, SPI, UART, CAN, etc.)
  • Mask testing

What’s In the Box

• DSOX3014T oscilloscope main unit
• 4 x N2843A passive probes (500 MHz, 10:1 attenuation)
• Calibration certificate (3-year calibration interval)
• Secure erase feature enabled
• Documentation CD (user guide, service guide, programmer manual)
• Localized power cord and overlay
• Multi-language interface

Warranty & Shipping

• Oscilloscope warranty: 3 years (parts & labor)
• Accessories (probes): 90 days warranty
• Calibration interval: 3 years
• Shipping options: FedEx, UPS, DHL with tracking

Installation & Setup

• Unpack and place on bench.
• Connect power cord.
• Attach probes to channels.
• Press Default Setup button.
• Touch screen to start measuring.
• No software install needed – ready out of box.

Debugging & Maintenance

• Clean screen with soft cloth.
• Run self-test from Utility menu.
• Update firmware via USB (free from Keysight).
• Probe compensation: use built-in 1kHz square wave.
• Secure erase removes all user data before resale.

Typical Applications

• Embedded design debugging (I2C, SPI, UART).
• Power supply testing and noise analysis.
• Automotive electronics (CAN, LIN).
• Education and university labs.
• Manufacturing test and validation.

5 Professional FAQs

• Q: Is DSOX3014T good for serial bus decoding?
  A: Yes. Add the serial decode license. Supports I2C, SPI, UART, CAN, LIN, and more.
• Q: Can I upgrade bandwidth later?
  A: Yes. All 3000T scopes are software-upgradable. Buy license and enter key.
• Q: What is Zone touch trigger?
  A: Draw a box on screen around your signal. Scope triggers only when signal enters that box. Very fast.
• Q: Does this scope have built-in function generator?
  A: Not standard. But you can add 20 MHz arbitrary waveform generator as an upgrade.
• Q: How deep is the memory?
  A: 4 Mpts standard. That is enough for most debugging tasks at 100 MHz.

Selection Guide & Buying Advice

• Need 100 MHz, 4 channels, touch screen? DSOX3014T is perfect.
• Need 200 MHz? Look at DSOX3024T (same family).
• For mixed signal (analog + digital): add digital probe later.
• For serial decode: buy the license at time of scope purchase (cheaper bundle).
• We sell Keysight DSOX3014T with full 3-year warranty. In stock.
• All upgrades available – just ask us for license keys.
