Description
Bently Nevada 3300 XL 8 mm Proximity Probe
A high-precision industrial sensor (330103-00-10-10-02-00) designed for vibration and position monitoring in demanding environments. Features stainless steel construction, extended temperature tolerance, and ATEX/IECEx certifications for hazardous areas.
Technical Data
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Proximity Probe
- Product No.: 330103-00-10-10-02-00
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 303/304 Stainless Steel
- Linear Range: 0.25–2.3 mm (10–90 mils)
- DC Resistance: 7.59 ±0.50 Ω (1.0 m length)
- Temperature Range: -52°C to +177°C (Standard), up to +260°C (Cable)
- Cable Length: 1.0 m (3.3 ft), extendable to 305 m (1,000 ft)
Installation & Compatibility
- Thread: M10x1 (max engagement 15 mm)
- Wiring: 0.2–1.5 mm² (16–24 AWG) shielded triad cable
- Compatible with Bently Nevada 3300 series monitors and intrinsically safe systems (via zener barriers or galvanic isolators).
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T1-T5, Class I/II/III
- Approved for Zone 0/2 and Division 1/2 hazardous areas
Important Notes
- Pressure Seal: Viton® O-ring (not pressure-tested by default).
- Avoid prolonged exposure below -34°C (-30°F) to prevent seal degradation.
Contact: For technical inquiries or custom requirements, email sales@ubestplc.com.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
