MTL5045 Signal Isolator: High-Power 800Ω Hazardous Area Solution
Ultra-Reliable Signal Transfer
The MTL5045 safely moves 4-20mA control signals into explosion zones. Delivers strong 16V power for demanding loads. Perfect for critical industrial applications.
Performance Highlights
- Model: MTL5045 Industrial Isolator
- Max Load: 800Ω in hazardous areas
- Voltage Power: 16V at 20mA output
- Input Drop: <4V at 20mA
- Accuracy: Better than 20µA
- Response: 250µs to 90% value
- Power Range: 20-35V DC
- Ripple: <40µA peak-to-peak
Wiring Made Simple
| Terminal | Function |
| 1 | Output (-ve) |
| 2 | Output (+ve) |
| 11 | Input (-ve) |
| 12 | Input (+ve) |
| 13 | Supply (-ve) |
| 14 | Supply (+ve) |
Safety Certified
Approved for:
• Zone 0, IIC, T4-T6 hazardous areas
• Division 1, Group A locations
Meets global safety standards
Expert Questions Answered
Q: What load capacity makes MTL5045 special?
A: Handles up to 800Ω – 60% more than standard isolators.
Q: How low is the voltage drop?
A: Only 4V at 20mA for efficient operation.
Q: What’s the maximum output voltage?
A: Delivers 16V at full 20mA load.
Q: Can it handle signal spikes?
A: Yes, manages 0-24mA range including overloads.
Q: Is special training needed?
A: No, simple terminal wiring for quick setup.
What’s Included
• MTL5045 isolator unit
• Installation guide
• Compliance papers
Your Purchase Protected
12-month product warranty
Global delivery via FedEx, UPS, DHL
Ships within 24 hours
