MTL Hazardous Area Switch Controller MTL5014 | Buy Now

Description

MTL5014: Dual-Relay Safety Commander

Control two safe devices with one hazardous-area switch! The MTL5014 barrier drives dual relays from explosive-zone sensors. Features smart fault detection. Zone 0 certified.

⚡ Relay Control Power

• Runs two devices from one hazardous sensor
• Instant 10ms relay response
• Smart line-fault detection
• Three-color status LEDs

???? Performance Specs

• Input: NAMUR/DIN 19234 sensors
• Sensor Voltage: 7-9V @ 1kΩ
• Relay Rating: 250V AC / 2A (40V DC)
• Contact Life: 300,000 operations
• LFD Detection: Open <100μA / Short >6.5mA
• Power: 20-35V DC (35-50mA)
• Isolation: 1500V AC protection
• Temp Range: -20°C to +70°C
• Response: <10ms switching

???? Terminal Setup

• 1,2: Hazard Input (-/+)
• 3: Earth Leakage Detect
• 7-9: Relay 2 (NC/C/NO)
• 10-12: Relay 1 (NC/C/NO)
• 13,14: Power (-/+)

????️ Secure Purchase

• 12-month worry-free coverage
• Fast global delivery: Fedex, UPS, DHL
• Tri-color LED diagnostics

???? Expert Insights

Q1: How many devices can MTL5014 control?
A: Two! Operates dual relays simultaneously.

Q2: What do the LED colors mean?
A: Green=power, Yellow=relay active, Red=line fault.

Q3: Can I reverse relay behavior?
A: Yes! Output 1 supports reverse phase.

Q4: What’s special about terminal 3?
A: Earth leakage detection for extra safety.

Q5: How durable are the relays?
A: Rated for 300,000 operations at full load.
