MTL5031 Vibration Monitor: Safe Signal Transfer from Hazardous Areas
Precision Vibration Monitoring
The MTL5031 safely transfers vibration signals from explosive zones to monitoring systems. Works with eddy-current probes and accelerometers. Essential for machine health monitoring.
Key Features
- Model: MTL5031 Vibration Interface
- Input Impedance: 10kΩ ±2%
- Output Impedance: <20Ω
- Frequency Range: DC to 20kHz
- Accuracy: ±1% (0-1kHz)
- Phase Response: <14µs delay
- Power Range: 20-35V DC
- Bandwidth: 43kHz (-3dB)
Easy Connections
| Terminal | Function |
| 1 | Common |
| 2 | Signal Input |
| 3 | Transducer Power |
| 11 | Signal (-ve) |
| 12 | Signal (0V) |
| 13 | Supply (-ve) |
| 14 | Supply (+ve) |
Safety Certified
Approved for:
• Zone 0, IIC, T4-T6 hazardous areas
• Division 1, Group A locations
Technical Questions
Q: What vibration sensors work with MTL5031?
A: Compatible with 3-wire eddy-current probes and accelerometers.
Q: How accurate is the signal transfer?
A: ±1% accuracy from DC to 1kHz.
Q: What’s the frequency response?
A: Flat response up to 43kHz (-3dB point).
Q: Can it power the transducer?
A: Yes, provides transducer power up to 26.6V.
Q: How fast is the response?
A: Less than 14µs phase delay.
Package Contents
• MTL5031 interface unit
• Installation manual
• Safety documentation
