Description

Pepperl+Fuchs K-LB-2.6 – Dual-Channel Surge Protector for 6V Systems

Advanced Protection for Sensitive Electronics

The K-LB-2.6 delivers professional-grade surge protection with its dual-channel design. This DIN rail mounted barrier automatically recovers after power surges, keeping your 6V systems safe from lightning strikes and electrical spikes.

Detailed Specifications

• Brand: Pepperl+Fuchs
• Model: K-LB-2.6 (Dual Channel Version)
• Voltage Rating: ≤6V DC
• Current Capacity: ≤250mA per channel
• Isolation Voltage: 500V DC
• Clamping Voltage: ≤12V line-to-line
• Response Time: 1ns (symmetrical)
• Bandwidth: ≥40kHz
• Terminals: Accepts 2.5mm² wires
• Dimensions: 12.5×114×110mm

Quick Setup Guide

1. Mount on standard 35mm DIN rail
2. Connect protected devices to terminals 5-6 and 7-8
3. Connect field wiring to terminals 1-2 and 3-4
4. Ensure proper grounding connection

Expert Questions Answered

1. Can this protect digital signals?
   Yes, its 40kHz bandwidth handles most digital signals.
2. How does the 500V isolation help?
   It prevents ground loops and protects against high voltage faults.
3. Is this suitable for outdoor use?
   Only in protected enclosures (IP20 rating).
4. What’s the advantage of dual channels?
   You can protect two separate circuits with one compact unit.
5. Can it handle repetitive surges?
   Yes, it’s rated for multiple 10kA surges.

Package & Support

Includes 1 surge protection unit. Ships via FedEx/UPS/DHL. Comes with 12-month product warranty.
