Description

Pepperl+Fuchs K-LB-1.6G – Ultra-Compact 6V Surge Protection Barrier

Essential Surge Defense for Sensitive Equipment

The K-LB-1.6G provides industrial-grade protection against dangerous voltage spikes. This single-channel barrier is specially designed for 6V systems, offering automatic recovery after surge events. Perfect for protecting delicate field instruments and control circuits.

Technical Specifications

• Brand: Pepperl+Fuchs
• Model: K-LB-1.6G (6V Surge Barrier)
• Voltage Rating: ≤6V DC
• Current Capacity: ≤250mA
• Peak Surge: 20kA (8/20µs single event)
• Response Speed: 1ns (symmetrical)
• Leakage Current: ≤5µA
• Bandwidth: ≥40kHz
• Connection: Screw terminals (2.5mm² max)
• Dimensions: 12.5×114×110mm
• Weight: 100g

Simple Installation

1. Mount on 35mm DIN rail
2. Connect protected side to terminals 7-8
3. Connect field side to terminals 1-2
4. Ensure proper grounding (critical for performance)

Professional FAQs

1. Can this protect 4-20mA signals?
   Yes, it’s ideal for analog signal protection.
2. What’s the difference from higher voltage models?
   The K-LB-1.6G is optimized for 6V systems with lower clamping voltage.
3. How does it compare to Zener barriers?
   Offers better surge protection while maintaining signal integrity.
4. Is special maintenance required?
   No – the auto-reset feature makes it maintenance-free.
5. Can multiple units be used together?
   Yes, for protecting multiple circuits in one panel.

Package & Support

Includes 1 surge barrier unit. Ships worldwide via FedEx/UPS/DHL. Backed by our 12-month satisfaction guarantee.
