Schneider Electric 170BDM09000 – Compact Discrete I/O for Momentum Series
Quick Overview
- Brand: Schneider Electric – global automation leader
- Series: Modicon Momentum – flexible distributed I/O
- Model: 170BDM09000 – 4 inputs + 2 digital outputs
- Prewiring supported – saves panel wiring time
- Lightweight: only 0.38 lbs (0.17 kg)
Technical Specifications (Tree Structure)
- General Information
- Manufacturer: Schneider Electric
- Product Line: Modicon Momentum
- Part Number: 170BDM09000
- Module Type: Discrete I/O Module
- I/O Configuration
- Number of Inputs: 4
- Number of Outputs: 2
- Output Type: Digital Outputs
- Prewiring Support: Yes (factory prewired options available)
- Environmental Limits (Operating)
- Temperature: 0 to 40 °C
- Max Humidity: 80% RH, non-condensing
- Environment: Clean indoor, no corrosive chemicals
- Max Altitude: 1000 m above sea level
- Environmental Limits (Storage)
- Temperature: 0 to 50 °C
- Max Humidity: 80% RH, non-condensing
- Max Altitude: 1000 m above sea level
- Physical
- Weight: 0.38 lbs (0.17 kg)
Key Features & Benefits
- Simple discrete control for small machines.
- Prewiring support reduces cabinet assembly time.
- Works inside clean industrial control panels.
- Lightweight design for easy installation.
- Compatible with Modicon Momentum backplanes.
Installation Guide (Simple Steps)
- Turn off power before handling the module.
- Align the 170BDM09000 with the Momentum base slot.
- Press firmly until the latch clicks into place.
- Connect prewired cables if available.
- Verify ambient temperature stays below 40°C.
- Avoid installing near heat sources or chemicals.
Typical Applications
- Small conveyor control (4 sensors, 2 actuators).
- Packaging machine discrete I/O expansion.
- HVAC equipment monitoring and control.
- Light industrial automation tasks.
- Building management systems.
Compatibility Info
- Fits Modicon Momentum I/O bases only.
- Use with Schneider Electric Momentum CPUs or adapters.
- For larger systems, consider Modicon Quantum series for high-density I/O.
- Not compatible with Modicon M340 or M580 directly.
Package Contents (No certificate or warranty note)
- 1 x Schneider Electric 170BDM09000 module
- Quick start guide (printed)
- No cables or prewiring harness included (sold separately)
Shipping Methods
- FedEx – 2 to 5 business days worldwide
- UPS – 3 to 4 business days
- DHL – 2 to 4 business days express
- Tracking number provided after shipment.
Frequently Asked Questions (FAQ) & Selection Guide
- Q1: How many inputs does the 170BDM09000 offer?
- It offers 4 discrete inputs and 2 digital outputs.
- Q2: Can this module work at 50°C ambient?
- No – max operating temperature is 40°C. Use forced cooling for higher temps.
- Q3: What type of outputs does it have?
- Digital outputs (on/off control). Output type details in the Momentum manual.
- Experience tip: Module not responding?
- Check if ambient humidity exceeds 80% non-condensing. Also verify altitude below 1000m.
- Selection guide: Choose 170BDM09000 or larger I/O?
- Pick this for small 4-in/2-out needs. For more points, see Modicon Quantum digital I/O modules.
- Warranty support: 12 months from delivery.
- We cover manufacturing defects free within 12 months.
