Description
Product Overview
The SICK C4C-SA10530A10000 belongs to the deTec4 Core family. This safety light curtain provides reliable hand and finger protection. It works without blind zones for complete coverage. Automatic calibration saves time during setup. The rugged design handles harsh conditions with ease.
Why Choose This Safety Light Curtain
No blind zones – complete protection across full height
Quick installation – FlexFix bracket allows ±15° alignment
Works in cold environments – operates from -30°C to +55°C
Dual enclosure rating – IP65 and IP67 protection
Highest safety level – Type 4, SIL3, PL e certified
Technical Specifications
• General Information
Brand: SICK
Model (Sender): C4C-SA10530A10000
Model (Receiver): C4C-EA10530A10000
Alternate P/N: 1211499
Series: deTec4 Core
Family: deTec Family
• Safety Ratings
Type: Type 4 (IEC 61496)
SIL: SIL3 (IEC 61508), SILCL3 (IEC 62061)
Category: Category 4 (ISO 13849-1)
Performance Level: PL e (ISO 13849-1)
PFHD: 3.7 x 10⁻⁹
Mission Time: 20 years
• Optical and Detection
Resolution: 30 mm
Protective field height: 1,050 mm
Scanning range: 15 m
Sensing range: 12 m
Response time: 11 ms
Blind zones: None
Synchronization: Optical
Wavelength: 850 nm
• Electrical Data
Supply voltage: 24 V DC (19.2 to 28.8 V)
Ripple: ≤ 10%
Power consumption: 2.11 W (DC) / 1.06 W (DC)
Protection class: III (IEC 61140)
OSSD outputs: 2 x PNP semiconductors
Output current: ≤ 300 mA per OSSD
ON voltage: 24 V DC (VS – 2.25 V to VS)
OFF voltage: ≤ 2 V DC
• Mechanical Data
Housing material: Aluminum extruded profile
Connector type: Male M12, 5-pin
Length: 41.34 inches (1,050 mm)
Weight: 970 g
• Environmental Protection
Enclosure rating: IP65 and IP67
Operating temperature: -30°C to +55°C
Storage temperature: -30°C to +70°C
Air humidity: 15% to 95% (non-condensing)
Vibration resistance: 5 g, 10 to 55 Hz
Shock resistance: 10 g, 16 ms
Installation and Alignment
Mount the sender and receiver facing each other. Use the FlexFix bracket for easy alignment. You can tilt the unit up to ±15° in any direction. The half-rounded housing rear lets you place brackets anywhere. Automatic calibration adjusts to the protective field width up to 10 meters. No special tools are required for setup.
Diagnostic Features
Integrated LED displays show system status at a glance. The unit performs self-checks continuously. If a fault occurs, at least one OSSD turns OFF. This creates a safe state automatically. The diagnostic functions help reduce downtime during maintenance.
Compatibility Information
This light curtain connects via M12 male connector (5-pin). It works with Versamax PLC systems. Integration is possible with Flexi Soft safety controllers. Fieldbus options include CANopen, DeviceNet, EtherCAT, EtherNet/IP, Modbus TCP, PROFIBUS DP, and PROFINET.
Typical Applications
Automated packaging machine access points
Robotic work cell perimeter guarding
Conveyor system hazard zones
Assembly line operator protection
Any area requiring hand or finger safety
What’s in the Box
Sender unit (C4C-SA10530A10000)
Receiver unit (C4C-EA10530A10000)
Test rod matching the 30 mm resolution
Safety instruction sheet
Mounting instructions
Operating instructions (download link provided)
Warranty and Shipping
We provide a 12-month warranty covering manufacturing defects. We ship worldwide using FedEx, UPS, or DHL. Tracking numbers are provided for all shipments.
Frequently Asked Questions (FAQ)
Q: What is the difference between sender (C4C-SA10530A10000) and receiver (C4C-EA10530A10000)?
A: The sender emits the infrared light beam. The receiver detects the beam and sends the safety signal.
Q: Can I use this curtain outdoors?
A: Yes, but avoid direct water spray. The IP65/IP67 rating handles rain, but long-term UV exposure may degrade the housing.
Q: How do I know if the alignment is correct?
A: Check the LED display on the receiver. A steady green light means proper alignment. Flashing indicates adjustment is needed.
Q: What happens if I buy only the sender (C4C-SA10530A10000) by mistake?
A: You need both sender and receiver for proper operation. Order the matching receiver (C4C-EA10530A10000) separately.
Q: Can I cut the cables to shorten them?
A: No. Cutting the cables voids the warranty and breaks the safety certification. Use extension cables instead.
Q: How do I clean the optical windows?
A: Use a soft, lint-free cloth with mild soap and water. Do not use abrasive cleaners or solvents.
Q: Does this curtain work with older SICK controllers?
A: It works with most Flexi Soft controllers. Check your controller firmware version before connecting.
Purchasing Guidance
First, measure your machine’s opening height. Choose the 1,050 mm version only if it fits your need. Second, confirm you need 30 mm resolution (finger protection). Third, check your ambient temperature range. This unit works down to -30°C. Fourth, verify your controller supports M12 5-pin connections. Fifth, order spare test rods for daily safety checks. Finally, buy a complete sender-receiver pair. The C4C-SA10530A10000 requires its matching receiver to function.
