TR Encoder CEV65M-01542 | Profibus DP Programmable

Description

Product Overview

• Brand: TR
• Model: CEV65M-01542
• Programmable encoder for flexible customer solutions.
• Works with Profibus DP interface.
• Offers modular mechanical design and product line.
• Supports further interfaces upon request.
• Uses RS485 output level.
• Fieldbus-device programming tool available.

Key Technical Data

• Steps per revolution: 8,192,000
• Number of revolutions: 4,096,000
• Interface: Profibus DP
• Code: Programmable
• Supply voltage: 11-27V DC
• Transmission rate: 9.6…12000 kbit/s
• Cycle time: 250 µs
• Resolution and output code: changeable via parameters
• Operating temperature: -20…+70°C
• Protection class: IP65
• Maximum speed (mechanical): ≤6000 1/min
• Angular acceleration: ≤10E+4 rad/s²
• Moment of inertia: 2.5E-6 kg m² (typical)
• Start-up torque at 20°C: 2 Ncm
• Mass: approx. 0.7 kg

Shaft & Flange Details

• Flange type: ZB36
• Shaft type: 10FL/19.5
• Shaft diameter options (mm): 6, 8, 10, 12, 14
• Shaft diameter (inch): 3/8
• Connector type: 3x PG9, radial position
• Mating plug not included.

Environmental & Mechanical Strength

• Vibration resistance: ≤100 m/s² (sine 50…2000 Hz)
• Shock resistance: ≤1000 m/s² (half sine 11 ms)
• Shaft load (axial/radial): ≤40 N / ≤60 N
• Bearing life: ≥3.9E+10 revolutions at 3000 1/min, 60°C, reduced load
• Immunity to disturbance: DIN EN 61000-6-2
• Transient emissions: DIN EN 61000-6-3
• Storage temperature (dry): -30…+80°C
• Relative humidity: 98% non-condensing

Programmable Functions

• Adjust resolution, output code, and counting direction.
• Set limit switches and gear function.
• Change velocity parameters and SSI parameters.
• Use external preset inputs for electronic adjustment.
• Logic level: “0” < +2V, “1” = supply voltage.

Installation & Wiring

• Connector position: PG radial.
• Use PG9 compatible cables (not included).
• Refer to drawing No. 04-CEV65M-M0003 for dimensions.
• Pinout reference: TR-ECE-TI-D-0017.
• Apply load at shaft end as specified.

Diagnostic Capabilities

• Programmable parameters allow active error checking.
• External preset inputs help verify position.
• Fieldbus tool provides real-time diagnostics.
• Monitor speed and counting direction easily.

Certifications & Standards

• EMC compliance with DIN EN 61000-6-2 and 61000-6-3.
• Protection class IP65 (standard).
• ECCN: N, AL: N for export ease.
• Firmware No. 437826, version 000.

Typical Applications

• Heavy-duty factory automation with Profibus DP networks.
• Position feedback for servo motors and conveyors.
• Printing, packaging, and textile machinery.
• Works well with 3300 XL 11 mm Proximity Probes for speed sensing.

Package Contents

• TR Encoder CEV65M-01542 – 1 unit.
• No mating plug or cable included.
• Documentation No. DOKUMENTE (refer to manual).

Warranty & Shipping

• 12-month warranty from shipment date.
• Covers manufacturing defects under normal use.
• Shipping partners: FedEx, UPS, DHL.
• Express delivery with full tracking.

FAQ – Frequently Asked Questions

• What is the maximum mechanical speed?
• 6000 1/min. Do not exceed this limit.
• Can I change the resolution after installation?
• Yes. Use the fieldbus device tool to reprogram parameters.
• Does the encoder work at -20°C?
• Yes, the optional range covers -20…+70°C.
• What happens if I overload the shaft?
• Exceeding 40N axial or 60N radial will reduce bearing life.
• Is the mating plug included?
• No. You need to order a mating plug separately.
• How do I set the counting direction?
• Use the programmable parameter via Profibus DP.

Expert Tips & Selection Guide

• Choose this model for Profibus DP networks needing high resolution.
• Select the -20…+70°C option for cold environments.
• Use external preset inputs for homing without a controller.
• For higher shaft loads, consider a different encoder series.
• Pair with 11 mm Proximity Probes for redundant speed monitoring.
• If you need SSI or other interfaces, ask about modular options.
• Keep total cable length suitable for 9.6…12000 kbit/s rates.
