Woodward 5464-836 Programmable Logic Controller Module
Quick Overview
The Woodward 5464-836 is a rugged PLC module. It comes from the MicroNet Plus series. This unit offers programmable logic for custom control tasks. It works in harsh industrial places. USA made and ready to ship.
Product Type & Classification
– Part Number: 5464-836 – Manufacturer: Woodward – Product Type: Programmable Logic Controller Module – Series: MicroNet Plus – Country of Manufacture: United States (USA) – Availability: In Stock
Hardware Features at a Glance
– Transceiver type: PLC Transceiver Module – Port configuration: Dual port – Mounting style: Panel mount – LED indication: No LED indication – Processor: Powerful and fast for real-time tasks – Chassis compatibility: MicroNet Plus chassis only
Technical Specifications
– Communication protocols: Ethernet, RS-232, RS-485 – I/O types: Analog and digital channels – Bus standard: VME (VERSAmodule Eurocard) – Motherboard: Etched-circuit type – Field wiring: Uses FTMs (Field Termination Modules) – Hazardous location rating: Class I, Division 2, Groups A, B, C, D – Relay modules: Only for non-hazardous locations – Ground leakage current: Greater than 3.5 mA – PE terminal: Requires grounding – Wiring type: Fixed wiring required
Functional Highlights
– Program logic based on your machine needs. – Fast data processing for time-sensitive jobs. – Detects faults and system problems quickly. – Helps reduce downtime with early warnings. – Works with Modicon Quantum systems via standard I/O.
Software & Programming
– Includes user-friendly programming software. – Offers ready-to-use libraries and tools. – Simplifies control logic changes. – Debugging features help find issues fast. – Engineers can fine-tune settings easily.
Installation Rules (Class I Div 2)
– Use only in Class I, Division 2, Groups A, B, C, D areas. – Non-hazardous locations are also allowed. – Follow Division 2 wiring methods exactly. – Local authority must approve your wiring plan. – Install fixed wiring only – no flexible cords. – Connect the input PE terminal to ground. – Ground leakage current exceeds 3.5 mA.
Chassis & Slot Rules
– The MicroNet Plus chassis has three blocks. – A motherboard connects all slots at the back. – Fans, switches, power supplies, and modules plug in. – Any I/O module fits any I/O slot physically. – Your software assigns each module to a fixed slot. – The system expects the same module in that slot always. – Do not swap slots after software is loaded.
Typical Applications
– Gas turbine control panels. – Steam turbine protection systems. – Engine management for diesel and gas. – Industrial process monitoring. – Retrofit of older Woodward logic modules. – Hazardous area control (Class I Div 2).
Warranty & Delivery
– Warranty: 12 months from ship date. – Covers defects in materials and workmanship. – Does not cover wiring errors or physical damage. – Shipping carriers: FedEx, UPS, DHL Express. – Tracking number provided for every order. – Worldwide delivery available.
FAQ – Professional Questions
What happens if I put a module in the wrong slot?
The software will not see the expected I/O type. The system may fault or ignore that module.
Can I use the 16-channel relay module in a hazardous area?
No. Relay modules are for non-hazardous locations only. The 5464-836 itself is fine for Class I Div 2.
How do I ground this unit correctly?
Connect the input PE terminal to earth ground. The leakage current is above 3.5 mA, so a solid ground is mandatory.
Does the warranty cover software issues?
No. The 12-month warranty covers hardware defects only. Programming errors are not included.
What is the lead time for a replacement 5464-836?
In-stock units ship within 24 hours via FedEx, UPS, or DHL. Contact us for exact delivery dates.
Selection Guide
– Choose 5464-836 for dual-port panel mount needs. – Pick this module if you need Class I Div 2 approval. – Select this unit for MicroNet Plus chassis only. – Order the 16-channel relay module separately for safe areas. – Confirm your slot assignment before installing software. – Need faster processing? This module has a powerful CPU. – For non-hazardous sites only? Relay version is another option.
