Description
Product Overview
Powerful & Reliable Genset Control
– Woodward 8440-2054 belongs to the easYgen-3000 Series. – It runs **32 gensets** in islanded or parallel operation. – This unit handles a single utility with total reliability. – Standardize distributed power generation using one controller. – Woodward raises industry standards for power management.
Smart Software & Easy Configuration
– Use simple software tools for fast configuration. – The controller supports multiple applications smoothly. – Enhanced connectivity ensures faster and safer interfacing. – Multi-lingual interface supports 13 languages including English, Chinese, Russian.
Complete Protection & Operation Modes
– Get full engine, generator, and utility protection. – Automatic Mains Failure (AMF) starts the genset when the grid fails. – Peak shaving operation reduces energy costs. – Supports open or closed transition switching.
Technical Specifications
Electrical & Measurement Data
– Brand: Woodward – Model: 8440-2054 – Series: easYgen-3000 Controller Series – Power Supply: 12/24 Vdc (range 8 to 40 Vdc) – Setting Range: 50 to 650,000 Vac – Max. Power Consumption per Path: less than 0.15 W – Measurement Range: 50 to 650,000 Vac – Frequency Response: Supports 50/60 Hz grid standards – Sensitivity: High precision for load sharing – Linearity: Excellent across full operating range – Resolution: Fine enough for critical protection tasks
Environmental & Mechanical Data
– Temperature Range: Operates reliably in -20°C to +70°C – Environmental Tolerance: Withstands humidity and vibration – Noise Immunity: High resistance to electrical interference – Back Panel Dimensions: 250W x 227H x 50mm D – Weight: Approx. 1,850 g (4 lbs)
Compatibility & Languages
– Compatible with: Most diesel and gas gensets – Works with Modicon Quantum PLC systems. – Supports Modbus RTU and TCP for easy integration. – Languages: English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish, Slovakian, Finnish, Swedish.
Installation, Maintenance & Diagnostics
Installation Guide
– Mount the unit on a flat, vibration-free panel. – Use 250W x 227H mm cutout for rear access. – Connect 8-40 Vdc power supply with proper fuse. – Follow the included wiring diagram for safety. – Keep 50mm clearance behind the panel for cooling.
Debugging & Maintenance Ease
– Easy access to all terminals for quick checks. – Use easYgen configuration software for fast debugging. – Firmware updates take less than 10 minutes. – LED indicators show power, run, and fault status. – No special tools needed for routine inspection.
Diagnostic Capabilities
– Real-time fault logging with time stamps. – Visual alarm list shows up to 100 events. – Built-in engine and generator parameter monitoring. – Pre-set protection curves for over/under voltage and frequency.
Certification, Packaging & Warranty
Certifications
– CE marked for European safety standards – UL listed for industrial control equipment – RoHS compliant for environmental safety
Package Contents
– One Woodward 8440-2054 easYgen-3000 controller – Mounting clips and screws – Terminal block connectors – Quick start guide (printed) – Software download card (no CD)
Warranty & Shipping
– Warranty: 12 months from invoice date. – Covers manufacturing defects only. – Shipping Carriers: FedEx, UPS, DHL. – Worldwide delivery with tracking number.
Typical Applications
Where to Use the 8440-2054
– Island mode power plants with multiple gensets – Data center backup power systems – Hospital emergency generator paralleling – Peak shaving at industrial facilities – Marine and offshore power management – Rental genset fleets for temporary power
FAQ – Experience-Based Answers & Selection Guide
Frequently Asked Questions
Q1: Can this unit run with different genset brands?
Yes. The 8440-2054 works with any brand if you use compatible voltage sensing and speed control.
Q2: How many engines can I connect in island mode?
Maximum 32 gensets. Each requires a separate easYgen-3000 unit and a CAN bus connection.
Q3: Does it support remote monitoring via mobile phone?
Not directly. Use a gateway like Woodward WebPro to enable remote access.
Q4: What if I lose utility mains during peak shaving?
The controller auto-switches to island mode. No power interruption to critical loads.
Q5: My screen shows “Sync Fail” error. What should I do?
Check voltage difference between bus and genset. Adjust the gain in the PID settings.
Buyer’s Selection Guide (Experience Tips)
– Choose this model if you need parallel control for 4+ gensets. – For a single genset without parallel, pick a cheaper easYgen-100 series. – Ensure your power supply stays above 10V during engine cranking. – Use shielded cables for CAN bus runs longer than 30 meters. – Buy the configuration cable and software license together.
