Product Introduction
Reliable Genset Control Without a Display
The Woodward 8440-2057 is a powerful genset control unit. It belongs to the easYgen-3000 series. This model is the easYgen-3100-P2 version. It has no built-in HMI. You manage it via PC using ToolKit software. The metal housing supports cabinet back mounting. It runs single or multi-unit operations.
High-Density Multi-Unit Management
This controller connects up to 32 units in parallel. It handles mains parallel operations well. The device also manages complex load management applications. It supports start/stop logic for gas and diesel engines.
Key Features (Bulleted List – No CSS)
1A CT inputs for precise current measurement
Metal housing without display for durability
External analog I/Os via CANopen protocol
Engine cylinder temperature protection included
Three freely configurable PID controllers
Twelve alarm outputs with ten configurable
Multilingual support and multi-level password protection
Technical Specifications
Measurement & Performance
Measuring Frequency: 50/60Hz (range 40 to 85 Hz)
Resolution: 11 Bit
Max power consumption per path: < 0.15 W
Linear CT inputs for generator load balance
Environmental & Tolerance
Operation Temperature: -20°C to 70°C
Housing material: Metal for industrial durability
Protection against mains phase shift or rotation field mismatch
Physical & Mounting
Front Panel Dimensions: 282W x 216H x 96D mm
Mounting type: Cabinet back mounting (no front display)
Intended for panel integration without direct viewing
Installation Guide
Mount the unit inside a protected cabinet
Use shielded cables for CANopen I/O connections
Connect 1A CT inputs to generator output lines
No front panel cutting needed for display access
Secure the metal housing with four mounting screws
Commissioning & Maintenance
Commission using Woodward ToolKit software via PC
No display means fewer components to fail
Update firmware through CANopen interface
Test alarms without engine running using software simulation
Regular checks: inspect wiring and CT connections
Compatibility
