3300 XL 11mm Probe Bently Nevada 330705-02-18-10-00-00 Reverse

Description

Quick Overview

• Bently Nevada 330705-02-18-10-00-00 is a 3300 XL 11 mm Reverse Mount Probe.
• Made in U.S.A.
• Thread type: 3/8-24 UNF.
• Total length: 1.0 meter (3.3 feet).
• Connector: Miniature ClickLoc coaxial.
• Weight: 0.07 Kg.

Model Number Breakdown

• 330705-02-18-10-00-00
  • 330705 = Base reverse mount probe
  • 02 = 3/8-24 UNF thread
  • 18 = 18 mm unthreaded length
  • 10 = 1.0 meter total length
  • 00 = Miniature ClickLoc connector
  • 00 = No agency approval

Technical Specifications

• Brand: Bently Nevada
• Full model: 330705-02-18-10-00-00
• DC resistance: 5.9 ± 0.5 ohms
• Cable type: 75 Ω triaxial, FEP insulated
• Tip material: Polyphenylene sulfide (PPS)
• Case material: AISI 304 stainless steel
• Minimum bend radius: 25.4 mm (1.0 inch)
• Max connector torque: 0.565 N•m (5 in•lb)
• Recommended torque: Finger tight only

Temperature Range

• Operating and storage: -52°C to +177°C (-62°F to +351°F)
• Avoid temperatures below -34°C (30°F) to protect pressure seal.

Pressure Seal

• Seal material: Viton O-ring between tip and case.
• Probes are not pressure tested before shipment.
• Contact custom design department for pressure seal test.

Hazardous Area Approvals

• ia (Intrinsic safety): AEx/Ex ia IIC T4/T5 Ga
• Suitable for Class I, Zone 0; Class I, II, III Divisions 1 and 2
• nA / ec (Nonincendive): AEx/Ex nA IIC T4/T5 Gc
• Suitable for Class I, Zone 2; Class I, Division 2
• T5 rating: -55°C to +40°C ambient
• T4 rating: -55°C to +80°C ambient

Installation Guide

• Mount using 3/8-24 UNF thread.
• Keep cable bend radius above 25.4 mm.
• Do not over-tighten ClickLoc connector.
• Finger tight provides reliable connection.

Maintenance and Debugging

• Measure DC resistance to check health.
• Good reading: 5.9 ± 0.5 ohms.
• Open or short circuit means replace probe.
• Inspect cable armor for cuts or damage.

Compatibility

• Works with Bently Nevada 3300 XL Proximitor sensors.
• Use with 75 ohm triaxial extension cables.
• For intrinsic safety: use zener barriers per drawing 141092.
• Compatible with galvanic isolators.

Warranty

• 12 months warranty from delivery date.
• Covers material and workmanship defects.

Shipping

• Carriers: FedEx, UPS, DHL.
• Express shipping available worldwide.
• Tracking number provided within 24 hours.

Typical Applications

• Reverse mount on turbine shafts.
• Axial thrust monitoring in compressors.
• Vibration measurement where front access is limited.
• Speed sensing on large rotating machinery.

Diagnostic Capabilities

• Detects micron-level shaft movement.
• Identifies bearing wear at early stage.
• Supports predictive maintenance programs.
• Works with Bently Nevada analysis software.

Frequently Asked Questions

• What does reverse mount mean?
  • Probe installs behind the target surface.
  • Ideal when front mounting space is not available.
• How to verify probe is functioning correctly?
  • Measure center to outer conductor resistance.
  • Should read 5.9 ± 0.5 ohms at room temperature.
• Signal drops intermittently. What to check?
  • Tighten ClickLoc connector finger tight plus 1/8 turn.
  • Inspect extension cable for damage.
  • Check for loose connections in the signal chain.
• Can this probe be used in Zone 0 areas?
  • Yes, with ia approval and proper zener barriers.
  • Follow Bently Nevada drawing 141092 for installation.
• How to select the right probe length?
  • Choose 1.0 meter for short cable runs near monitor.
  • Select 5 or 9 meters for remote mounting.
  • Longer cables require no signal adjustment.
