Description
Bently Nevada Long-Reach Proximity Probe
Product Overview
- Part Number: 330707-00-30-90-02-00
- Model: 3300 XL 11 mm Probe
- Made in USA (COO available)
- Warranty: 12 months
Configuration Details
- 330707 – Base model (5/8-18 UNF thread)
- 00 – Unthreaded length: 0 inch
- 30 – Case length: 3.0 inch
- 90 – Cable length: 9.0 meters
- 02 – Standard ClickLoc connector
- 00 – No agency approvals
Technical Specifications
| Cable Length | 9.0 meters (29.5 feet) |
| Electrical Resistance | 8.5 ± 1.1 Ω |
| Case Material | AISI 304 stainless steel |
| Tip Material | PPS polymer |
| Installation Torque | 15.2 N•m max |
| Temperature Range | -51°C to +177°C |
Installation Guide
- Max thread engagement: 0.938 inch
- Finger tighten plus 1/4 turn
- Minimum bend radius: 25.4 mm
- Do not expose below -34°C
Shipping Information
- Weight: 0.17 kg
- Carriers: FedEx / UPS / DHL
- Delivery: Worldwide
- Packaging: Factory sealed
Common Questions
Q: How long is the cable?
A: This model has 9 meters (29.5 feet)
Q: What is the resistance value?
A: 8.5 Ω with ±1.1 Ω tolerance
Q: Minimum installation temperature?
A: Keep above -34°C to protect seals
Q: Cable bend restrictions?
A: Minimum 25.4 mm bend radius
