Bently Nevada 3300 XL 11mm Proximity Probe: Heavy-Duty Industrial Monitoring
Core Features
- ✅ Made in USA with optional Certificate of Origin
- ✅ 5-meter triaxial cable with ClickLoc connector
- ✅ Viton O-ring seal for pressure environments
- ✅ Chemical-resistant PPS tip & stainless steel body
Complete Suffix Breakdown
| Code Segment | Meaning |
|---|---|
| 330708 | 3300 XL 11mm Probe (5/8-18 UNF thread) |
| -00- | 0″ unthreaded length |
| -24- | 2.4″ overall case length |
| -50- | 5.0 meter cable |
| -01- | Miniature ClickLoc connector |
| -00 | No agency approval required |
Critical Specifications
- Brand/Model: Bently Nevada 330708-00-24-50-01-00
- Thread Type: 5/8-18 UNF
- Max Thread Engagement: 0.938 inches
- Probe Resistance: 7.2Ω ±0.8Ω (5m cable)
- Temperature Range: -51°C to +177°C
- Bend Radius: >25.4mm (1.0 inch)
- Shipping Weight: 0.17 kg
Torque Specifications
- Recommended: 15.2 N•m (133 in•lb)
- Maximum: 45.2 N•m (400 in•lb)
- Connector Torque: Finger tight (max 0.565 N•m)
Pressure & Sealing
Viton O-ring seals differential pressure. Warning: Temperatures below -34°C may damage seal. Contact for custom pressure testing.
Cable Compatibility
Requires 75Ω triaxial FEP cables. Exclusive use: Only compatible with 5-meter Proximitor Sensors.
Shipping & Warranty
Ships globally via FedEx/UPS/DHL. Includes 12-month manufacturer warranty.
Technical FAQ
Q: Minimum installation temperature?
A: Do not install below -34°C to prevent seal damage
Q: Compatible cable lengths?
A: Only 1m, 5m or 9m triaxial FEP cables
Q: Thread specifications?
A: 5/8-18 UNF with 0.938″ max engagement
Get Installation Guide
Download torque settings and temperature guidelines: Click for Probe Manual
