Description
Product Summary
- Brand: Honeywell
- Model: 8C-PAIM01
- Part Number: 51454358-175
- Series: 8C Series
- Module Type: Low-Level Analog Multiplexer
- Built for precise signal routing
- Designed for sensitive analog inputs
Why Choose This Module
- High signal accuracy for low-level measurements
- Supports single-ended and differential wiring
- Wide temperature tolerance
- Compact and lightweight design
- Stable performance in noisy environments
Electrical & Signal Performance
- Input Channels: 8
- Input Configuration: Single-ended or differential
- Input Impedance: 2 MΩ
- Common-Mode Rejection: 60 dB
- Gain Adjustment: -2 to +2
- Offset Control: ±10 V
- Signal Bandwidth: Optimized for low-level analog data
- Linearity: High across full input range
- Noise Performance: Low drift and low cross-talk
Power & Environmental Data
- Supply Voltage: 24 VDC
- Power Use: 5 W
- Operating Temperature: -40 to 85 °C
- Humidity Range: 0 to 95% non-condensing
- Thermal Stability: Suitable for continuous operation
Mechanical Details
- Dimensions: 100 x 60 x 25 mm
- Weight: 200 g
- Mounting: Standard control cabinet
- Form Factor: Space-saving module
Installation Notes
- Supports clean signal grounding
- Short cable runs recommended
- Easy access terminals
- Quick integration into analog systems
Operation & Maintenance
- No routine calibration required
- Stable gain reduces adjustment work
- Consistent readings over time
- Simple replacement during shutdowns
System Compatibility
- Designed for Honeywell control platforms
- Works with analog input subsystems
- Ideal for mixed-signal architectures
Application Scenarios
- Process instrumentation systems
- Low-level sensor signal collection
- Test and measurement panels
- Industrial data acquisition
Packaging & Warranty
- Industrial protective packaging
- 12-month warranty
- Factory-tested before shipment
Shipping Methods
- Fast international dispatch
- FedEx priority service
- UPS global shipping
- DHL express delivery
FAQ
- What signals suit this module best?
- Low-voltage and low-noise analog signals.
- How can accuracy be improved?
- Use shielded cables and proper grounding.
- Is it safe for outdoor cabinets?
- Yes, with proper enclosure protection.
- What is a field engineer tip?
- Separate analog and power wiring paths.
- How do I choose the right multiplexer?
- Match channel count, gain range, and signal type.
